GENERAL
Mains voltage
-/10:
-/01 120/230 V
:
-/10 240 V
: -/01 : 60 / 50 Hz Mains frequency
: :50 Hz
Battery mains : 9 V (R14 x 6)
Power consumption : 15W
AMPLIFIER
Output power mains : 2 x 1.5 W
battery : 2 x 1.5 W
Speaker impedance : 2 x 6 ohm
TUNER - FM SECTION
Tuning range : 87.5 - 108 MHz
IF frequency : 10.7 MHz
Sensitivity : < 14 dBµV at 26dB S/N
Selectivity S9/300kHz : > 20 dB ±0.3MHz
IF rejection : > 50 dB
Image rejection : > 20 dB
-3dB limiting point : 18dBµV
Distortion : 5%
TUNER - MW SECTION
Tuning range : 526.5 - 1606.5 kHz
IF frequency : 456 kHz ± 3 kHz
Sensitivity : < 72 dBµV/m at 26dB S/N
Selectivity : 16 dB
:
Channel difference dB
:
Overall frequency responce
AUDIO CASSETTE RECORDER
Number of tracks : 1 stereo
Tape speed : 4.76 cm/sec + 3/-2%
Wow & flutter : < 0.35 % JIS Unwtd.
Fast wind/rewind C60 : < 130 sec.
Frequency response P/B : 125 - 8000 Hz
S/N ratio : > 36 dB120Hz 3 :
IF rejection 24 dB
:
Image rejection ratio 28 dB> > >
COMPACT DISC
:
S/N ratio unwtd. > 50 dB
Channel difference 1 kHz : < 2 dB
Crosstalk 1 kHz : > 30 dB
Frequency response :± 2dB at 100Hz
THD(1kHz,0dB) : 1.5%
2 - 1
SERVICE TOOLS
Audio signal disc SBC 429.......................................................................4822 397 30184
Playability test disc SBC 444...................................................................4822 397 30245
Test disc 5(disc without errors ) +
Test disc 5A(disc with dropout errors, black spots and fingerprints)
SBC 426/426A.....................................................................4822 397 30096
Burn in test disc (65 min. 1kHz signal at -30 dB level without pause)
.....4822 397 30155
anti-static table mat
large 1200x650x1.25mm 4822 466 10953
small 600x650x1.25m 4822 466 10958
anti-static wristband4822 395 10223
connection box (3 press stud connections, 1M-„¦ ) 4822 320 11307
extendible cable (2m, 2M-„¦ , to connect wristband to connection box) 4822 320 11305
connecting cable (3m, 2M-„¦ , to connect table mat to connection box) 4822 320 11306
earth cable (1M-„¦ , to connect any product to mat or to connection box) 4822 320 11308
KIT ESD3 (combining all 6 prior products - small table mat) 4822 310 10671
wristband tester4822 344 13999
AVAILABLE ESD PROTECTION EQUIPMENT
