Page: 1 / 25
Extracted text from philips az 3038 service manual (Ocr-read)
Mains voltage -/00C :230 V
/05:240V
Mains frequency -/00C/05 : 50 Hz
Battery main set : 9 V (R14 x 6)
Power consumption : < 20 W (max.)
Dimension (W x H x D) : 294 x 145 x 245 mm
Weight :2.4 Kg
Output power mains : 2 x 1 W
battery : 2 x 1 W
Speaker impedance : 2 x 8 ohm
Frequency response :100 Hz - 10 kHz (±3dB)
Frequency response :100 Hz - 10 kHz ± 2dB
S/N ratio : 60 dB
Channel difference 1 kHz : 2 dB
Channel crosstalk 1 kHz : 40 dB
Laser wavelength :780 ± 20 nm
Laser light power : < 0.5 mWTuning range : 87.5 - 108 MHz
IF frequency : 10.7 MHz ± 0.2 MHz
Sensitivity : 20 dBf at 26dB S/N
Selectivity : 30 dB at 300kHz
IF rejection : 50 dB
Image rejection : 20 dB
Crosstalk : 20 dB
Tuning range MW : 531 - 1602 kHz
IF frequency:450 kHz ± 1 kHz
Sensitivity MW :4500 µV/m at 26dB S/N
Selectivity MW : 16 dB
IF rejection MW : 60 dB
Image rejection MW : 28 dB
TECHMICAL SPECIFICATIONS
GENERAL
AMPLIFIER
COMPACT DISCTUNER - FM SECTION
TUMER - AM SECTION
2 - 1
SERVICE TOOLS
Audio signal disc SBC 429.......................................................................4822 397 30184
Playability test disc SBC 444...................................................................4822 397 30245
Test disc 5(disc without errors ) +
Test disc 5A(disc with dropout errors, black spots and fingerprints)
SBC 426/426A.....................................................................4822 397 30096
Burn in test disc (65 min. 1kHz signal at -30 dB level without pause)
.....4822 397 30155
anti-static table mat
large 1200x650x1.25mm 4822 466 10953
small 600x650x1.25m 4822 466 10958
anti-static wristband4822 395 10223
connection box (3 press stud connections, 1M-„¦) 4822 320 11307
extendible cable (2m, 2M-„¦, to connect wristband to connection box) 4822 320 11305
connecting cable (3m, 2M-„¦, to connect table mat to connection box) 4822 320 11306
earth cable (1M-„¦, to connect any product to mat or to connection box) 4822 320 11308
KIT ESD3 (combining all 6 prior products - small table mat) 4822 310 10671
wristband tester4822 344 13999
AVAILABLE ESD PROTECTION EQUIPMENT
