GENERAL
Mains voltage :
-/00C -/00C/01/05
-/17
-/00C/05230 V
:
-/01 230V/120 V
:
-/05 240V
:
-/17 120 V
Mains frequency ::50 Hz
: -/01 : 50 Hz/60Hz
: -/17 : 60Hz
Battery mains : 12 V (R20 x 8)
Power consumption :
Dimension (W x H x D) : 480 x
260 x 170 mm
Output power mains : 2 x 4 W
battery : 2 x 4 W
TUNER - FM SECTION
Tuning range : 87.5 - 108 MHz
IF frequency : 10.7 MHz
26dB quieting sensitivity : < 14dBuV
Selectivity S300 : > 15 dB ±0.2MHz
S/N Ratio(A-Wtd) : > 45dBA
IF rejection : > 50 dB
Image rejection : > 20 dB
Output power at 10%THD : > 4000 mW
AM suppression : > 22 dB
TUNER - MW SECTION
Tuning range : 531 - 1602 kHz
:530 - 1710 kHz
IF frequency : 450 kHz ± 3 kHz
26dB quieting sensitivity : < 74 dB/m
Selectivity : 16 dB
:
IF rejection ratio 24 dB
:
Image rejection 28 dB
< 24 W
Frequency response :> >
:
Output power at 10%THD 3800mW
:
Frequency responce -6dB<100Hz > >
COMPACT DISC
:
S/N ratio > 50 dB
:
< 2 mV+0dB ±3dB at 125Hz Channel difference : < 3 dB
:
THD (1KHz,0dB) <1.5%
:
Frequency accuracy +/-0.5% Crosstalk
1 kHz : > 26 dB
Crosstalk
10 kHz : > 16 dB at S9/300kHz
(1kHz ref.)
Residual hum & noise
:
< 2 mV
:
< 500 mA Current consumption
:
>4000mW
Rated power 10%THD/1KHz-Rated output
2 - 1
SERVICE TOOLS
Audio signal disc SBC 429.......................................................................4822 397 30184
Playability test disc SBC 444...................................................................4822 397 30245
Test disc 5(disc without errors ) +
Test disc 5A(disc with dropout errors, black spots and fingerprints)
SBC 426/426A.....................................................................4822 397 30096
Burn in test disc (65 min. 1kHz signal at -30 dB level without pause)
.....4822 397 30155
anti-static table mat
large 1200x650x1.25mm 4822 466 10953
small 600x650x1.25m 4822 466 10958
anti-static wristband4822 395 10223
connection box (3 press stud connections, 1M-„¦) 4822 320 11307
extendible cable (2m, 2M-„¦, to connect wristband to connection box) 4822 320 11305
connecting cable (3m, 2M-„¦, to connect table mat to connection box) 4822 320 11306
earth cable (1M-„¦, to connect any product to mat or to connection box) 4822 320 11308
KIT ESD3 (combining all 6 prior products - small table mat) 4822 310 10671
wristband tester4822 344 13999
AVAILABLE ESD PROTECTION EQUIPMENT
TECHNICAL SPECIFICATIONS
