GENERAL
Mains voltage
:
-/01 120V/230 V
:
-/10 240 V
Mains frequency
: -/01 : 60 Hz/50Hz
: -/10 : 50 Hz
Battery
mains : 12 V (R20 x 8)
Power consumption
:
Dimension (W x H x D)
:
480 x
260 x 170 mm
AMPLIFIER & MAX PART
Output power mains : 2 x 4 W
battery : 2 x 4 W
Residual noise : 60nW (volume minimum)
Channel difference : 3dB typ. at 500mW
Hum & noise : 500nw (Vol.max.-20dB)
TUNER - FM SECTION
Tuning range : 87.5 - 108 MHz
IF frequency : 10.7 MHz
Sensitivity : < 25 dBf at 26dB S/N
Selectivity : > 20 dB at S9/300kHz ±0.02MHz
IF rejection : > 50 dB
Image rejection : > 20 dB
TUNER - MW SECTION
Tuning range :
:9kHz 531 - 1602 kHz
10kHz 530 - 1700 kHz
IF frequency : 450 kHz ± 1 kHz
Sensitivity : < 5000 µV/m at 26dB S/N
Selectivity : 16 dB
:
IF rejection ratio 24 dB
:
Image rejection 28 dB < 24 W
Frequency response :> >
>
COMPACT DISC
:
S/N ratio > 50 dB
:
> 5 g+10dB ±2dB at 100Hz Channel difference : < 3 dB
:
THD (1KHz,-6dB) <1%
:
THD (10KHz,-20dB) <3%
Crosstalk
1 kHz : > 26 dB
Crosstalk
10 kHz : > 16 dB at S9/300kHz
(500mW output WOOX ON)
Frequency response : +1dB ±2dB at 10kHz
(500mW output WOOX ON)
Shock resistance
±Z axis
:
> 5 g
±X or ±Y axis
:
35dBAmax.(mode:play/pause)
Acoustical noise
:
45dBAmax. (mode:jump)
2 - 1
SERVICE TOOLS
Audio signal disc SBC 429.......................................................................4822 397 30184
Playability test disc SBC 444...................................................................4822 397 30245
Test disc 5(disc without errors ) +
Test disc 5A(disc with dropout errors, black spots and fingerprints)
SBC 426/426A.....................................................................4822 397 30096
Burn in test disc (65 min. 1kHz signal at -30 dB level without pause)
.....4822 397 30155
anti-static table mat
large 1200x650x1.25mm 4822 466 10953
small 600x650x1.25m 4822 466 10958
anti-static wristband4822 395 10223
connection box (3 press stud connections, 1M-„¦) 4822 320 11307
extendible cable (2m, 2M-„¦, to connect wristband to connection box) 4822 320 11305
connecting cable (3m, 2M-„¦, to connect table mat to connection box) 4822 320 11306
earth cable (1M-„¦, to connect any product to mat or to connection box) 4822 320 11308
KIT ESD3 (combining all 6 prior products - small table mat) 4822 310 10671
wristband tester4822 344 13999
AVAILABLE ESD PROTECTION EQUIPMENT
TECHNICAL SPECIFICATIONS
