Page 1
Finding a passage within a
track
1During playback, press and hold down
-ˆžor §
.
-žœThe disc is played at high speed and low
volume.
2When you recognize the passage you want,
release -ˆžor §
toresume normal playback.
Programming tracks You may store up to 20 tracks in the desired
sequence. If you like, store any track more
than once.
1In the stop position,press PROGto activate
programming.
-žœDisplay shows P01indicating the star t of
the program and PROG flashes.(See 6)
2Press
-ˆž
or §
to select your desired track
number.
For MP3-CD/WMA:First press
ALBUM
+/- once or more to find your album.
3Press PROG to store the desired track.
-žœDisplay shows P02,indicating the next
program location available.
4Repeat steps 2to 3to select and store all
desired tracks.
5Press
2;
to play the program.
To review your program
In the stop position, press and hold PROG3
seconds.
-žœThe display shows all the stored tracks in
sequence.
Helpful hints:
-“Display shows P01 if no track is
programmed.
-“If you tr y to store more than 20 tracks, no
track can be stored and the display will show
--- with PROG.Erasing a program
You can erase a program by:
-“ pressing
9 (twice during playback or once
in the stop position);
-“ selecting FM,MW or OFFposition;
-“ opening the disc door.
-žœ Display:PROGdisappears.
Selecting different play
modes (See 7) You can select and change the various play
modes before or during playback, and
combine REP or REP ALL play modes with
PROG.
REP-“ plays the current track continuously.
REP ALL-“ plays the entire disc/program
continuously.
SHUF-“ plays all tracks in random order
(not available with PROG).
1To select play modes, press MODEonce or
more.
2Press2;to star t playback if in the stop
position.
3To select normal playback, press MODE
repeatedly until the various modes are no
longer displayed.
-“ You can also press9to cancel your play
modes.
MP3-CD / CD Player
USB Connection
Using USB connectivity
-AZ1833 is fitted with a USB por t in the front
panel, offering a plug and play feature which
allows you to play, from your AZ1833, digital
music and spoken contents stored on a USB
mass storage device.
-Using a USB mass storage device, you can
also enjoy all the features offered by AZ1833
which are explained and instructed in the
sections of disc operation.
Compatible USB mass storage devices
With the AZ1833, you can use
-“ USB flash memor y (USB 2.0 or USB 1.1)
-“ USB flash player (USB 2.0 or USB 1.1)
- USB device which requires driver
installation under Windows XP is not
suppor ted.
Note:
In some USB flash players (or memor y
devices), the stored contents are recorded
using copyright protection technology. Such
protected contents will be unplayable on any
other devices (such as AZ1833 device).
Supported formats:
-“ USB or memor y file format FAT12, FAT16,
FAT32 (sector size: 512 - 4096 bytes)
-“ MP3 bit rate (data rate): 32-320 kbps and
variable bit rate
-“ WMA v9 or earlier
-“ Director y nesting up to a maximum of 8
levels
-“ Number of albums: maximum 500
-“ Number of tracks: maximum 999
-“ ID3 tag v2.0 or later
-“ File name in Uicode UTF8 (maximum
length: 30 bytes
The system will not play or support
the following:
- Empty albums: an empty album is an album
that does not contain MP3/WMA files, and
will not be shown in the display.- Non-suppor ted file formats are skipped.
This means that e.g.: Word documents .doc
or MP3 files with extension. dlf are ignored
and will not be played.
- AAC, WAV, PCM. NTFS audio files
- DRM protected WMA files
- WMA files in Lossless format
Playing a USB mass storage device
1Make sure that your AZ1833 is being
powered by AC mains or specified batteries.
2Adjust the source selectorto
CD/USB/AUX.
-žœDisplay shows - - - with DISC(see 2),
or - - - with USB (see 3)
3Press USB to enter USB mode if USB is
NOT displayed.
-žœDisplay will show USB (see 3).
4As shown in figure 9,plug a compatible
USB mass storage device to AZ1833s USB
por t marked . If needed, use a suitable
USB cable to connect between the device
and AZ1833s USB por t.
-žœThe device will automatically power on.
-If the device is not powered on, turn on the
power manually, then re-connnect it.
-žœAZ1833s display shows USB and the total
number of playable audio files (Max.
displayed track number is 999) stored on
the device.
5Press
2;on your AZ1833 to star t play.
-žœAZ1833s display will show USB and share
the display information illustrated in the
disc operation.
Helpful hints:
-“ Make sure that file names of MP3 files end
with .mp3. and the file names of WMA files end
with .wma.
-“ For DRM protected WMA files, use Windows
Media Player 10 (or later) for conversion. Visit
www.microsoft.com for details about Windows
Media Player and WM DRM (Windows Media
Digital Rights Management).
-“ For USB device playing, if the display shows
"OL", it means that the USB device is electrically
overloading AZ1833. You need to change a USB
device.
X
USB DISC DISC DISC DISC DISC
WMA
USB mass
storage device
USB cable
2
8
3
6
7 4
5
No sound/ power -“Volume not adjusted
-Adjust the VOLUME
-“Power cord not securely connected
-Connect the AC power cord properly
-“Batteries dead/ incorrectly inserted
-Inser t (fresh) batteries correctly
-“Disc contains non-audio files
-Inser t a suitable disc or press
-ˆž or §
once or
more skip to an audio track, instead of the data
files.
Display does not function properly/No
reaction to operation of any of the controls -“Electrostatic discharge
-Switch off and unplug the set. Reconnect after a
few seconds. noindication -“It is set in the USB mode.
-Press CDto select CD mode.
-“No disc inserted
-Inser t a suitable disc
-“Disc badly scratched or dirty
-Replace/clean CD (See Maintenance)
-“CD-R(W) is blank or the disc is not finalized.
-Use a finalized CD-R(W)
-“Laser lens steam up
-Wait until lens has cleared. Note:
Make sure the CD is not encoded with
Copyright protection technologies, as some
do not conform to the Compact
Disc standard. The disc skips tracks-“Disc damaged or dirty
-Replace or clean disc
-“Shuffle or program is active
-Quit shuffle/program
Sound skips during MP3 playback
-“MP3 file made at compression level exceeding
320kbps
-Use a lower compression level to record CD
tracks into MP3 format -“Disc damaged or dirty
-Replace or clean disc. Note:
DRM-protected WMA disc is not supported.
The USB device doesnt play on my AZ1833 -“It is not set in the USB mode.
-Press USBto select USB mode.
-“The device is not securely connected to AZ1833s
USB port.
-Re-connect the device, and make sure that the
device is powered on.
-“The device is not supported by AZ1833, or the audio
file format stored on the device is not supported by
AZ1833.
-Use a compatible device/ playable audio file
format.
Troubleshooting If a fault occurs, first check the points listed below before taking the set for repair.
If you are unable to remedy a problem by following these hints, consult your dealer or ser vice centre. WARNING:
Do not open the set as there is a risk of electric shock. Under no cir-
cumstances should you try to repair the set yourself, as this will inval-
idate the guarantee.
Safety information
-Place the set on a hard, flat and stable surface
so that the system does not tilt.
-Do not expose the set, batteries, CDs to
humidity, rain, sand or excessive heat caused
by heating equipment or direct sunlight.
-Where the MAINS plug or an appliance cou-
pler is used as the disconnect device, the dis-
connect device shall remain readily operable.
-The apparatus shall not be exposed to
dripping or splashing.
-Adequate ventilation with a minimum gap of
15 cm between the ventilation holes and sur-
rounding surfaces is necessar y to prevent
heat build-up.
-The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers, table-cloths, cur tains, etc..
-No objects filled with liquids, such as vases,
shall be placed on the apparatus.
-No naked flame sources, such as lighted can-
dles, should be placed on the apparatus.
-The mechanical par ts of the set contain
self-lubricating bearings and must not be oiled
or lubricated.
-To clean the set, use a dr y cloth. Do not use
any cleaning agents containing alcohol,
ammonia, benzene or abrasives as these may
harm the housing.
CD player and CD handling
-If the CD player cannot read CDs correctly,
use a cleaning CD to clean the lens before
taking the set to repair.
-The lens of the CD player should never be
touched!
-Sudden changes in the surrounding
temperature can cause condensation on the
lens of your CD player. Playing a CD is then
not possible. Do not attempt to clean the
lens but leave the set in a warm environment
until the moisture evaporates.
-Always close the CD door to avoid dust on
the lens.
-To clean the CD, wipe in a straight line from
the center towards the edge using a soft,
lint-free cloth. Do not use cleaning agents as
they may damage the disc.
-Never write on a CD or attach any stickers
to it.
Safety & Maintenance
(See 8) Environmental information All unnecessar y packaging material has been omitted. The packaging can be easily separated
into three materials: cardboard, polystyrene and plastic.
Your set consists of materials which can be recycled if disassembled by a
specialized company. Please observe the local regulations regarding the
disposal of packaging, dead batteries and old equipment.
Disposal of your old product
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When this crossed-out wheeled bin symbol is attached to
a product it means the product is covered by the
European Directive 2002/96/EC
Please inform yourself about the local separate collection
system for electrical and electronic products.
Please act according to your local rules and do not dis-
pose of your old products with your normal household
waste. The correct disposal of your old product will help
prevent potential negative consequences for the environ-
ment and human health.
9
6 x R14 - UM-2 - C-CELLS
8 9 0 ! # $
1 2 4 @ % 3
AC MAINS~AUX IN
5 6 7 4 1
INFORMATION REGARDING USB DIRECT:
1. Compatibility of the USB connection on this product:
a) This product suppor ts most USB Mass storage devices (MSD) that these devices are compli-
ant to the USB MSD standards.
i) Most common Mass storage class devices are flash drives, memor y sticks, jump drives and
etc.
ii) If you see a "Disc Drive" showing up on your computer after you have plugged the mass
storage device into your computer, most likely it is MSD compliant and it will work with
this product.
b) If your Mass storage device requires a batter y/power source, please make sure you have a
fresh batter y in it or charge the USB device first and then plug it into this product again.
2. Suppor ted Music type:
a) This device only suppor ts unprotected music with file extension: .mp3 .wma
b) Music bought from on-line music stores are not suppor ted because they are secured by
Digital Rights Management protection (DRM).
c) File name extensions that ended with the following are not suppor ted: .wav; .m4a; .m4p;
.mp4; .aac and etc.
3. No Direct connection can be made from a Computer USB por t to this product even you have
either or both mp3 or wma file in your computer.
AZ1833_05 2007.7.17 16:32 Page 2
