GENERAL
Mains voltage :-/00/05
-/00/05 230 V
:
-/17 -/17 120 V
Mains frequency : :
50 Hz
:
-/17 : 60 Hz
Battery mains : 9 V (R14 x 6)
Power consumption :
Dimension (L x D x H) : 360 x 225 x 152 mm
Weight : 2.3 Kg
AMPLIFIER
Output power mains : 2 x 1 W
battery : 2 x 1 W
Speaker impedance : 2 x 8 ohm
Frequency response : 100 Hz -10 kHz ( ±2dB)
TUNER - FM SECTION
Tuning range : 87.5 - 108 MHz
IF frequency : 10.7 MHz
Sensitivity : < 22 dBf at 26dB S/N
Selectivity : > 20 dB at ±300kHz
± 0.2MHz
IF rejection : > 50 dB
Image rejection : > 20 dB
TUNER - MW SECTION
Tuning range : 520 - 1602 kHz :530 - 1700 kHz
IF frequency : 450 kHz ± 1 kHz
Sensitivity : < 5000 µV/m at 26dB S/N
Selectivity : 16 dB :
IF rejection ratio 24 dB
:
Image rejection ratio 28 dB
AUDIO CASSETTE RECORDER
Number of tracks : 1 stereo
Tape speed : 4.76 cm/sec ± 3%
Wow & flutter : < 0.35 % JIS UWTD
Fast wind/rewind C60 : < 130 sec.
< 5 W typ.
Frequency response P/B : 125 - 8000 Hz
S/N ratio : > 36 dB > >
>
COMPACT DISC
:
S/N ratio > 50 dB
Channel difference 1 kHz : < 3 dB
Channel crosstalk 1 kHz : > 26 dB
Laser wavelength : 780 ± 20nm
Laser light power : < 0.3 mW
2 - 1
SERVICE TOOLS
Audio signal disc SBC 429.......................................................................4822 397 \
30184
Playability test disc SBC 444 ...................................................................4822 \
397 30245
Test disc 5 (disc without errors ) +
Test disc 5A (disc with dropout errors, black spots and fingerprints)
SBC 426/426A .....................................................................482\
2 397 30096
Burn in test disc (65 min. 1kHz signal at -30 dB level without pause)
.....4822 397 30155
anti-static table mat
large 1200x650x1.25mm 4822 466 10953
small 600x650x1.25m 4822 466 10958
anti-static wristband 4822 395 10223
connection box (3 press stud connections, 1M -„¦) 4822 320 11307
extendible cable (2m, 2M-„¦, to connect wristband to connection box) 4822 320 11305
connecting cable (3m, 2M-„¦, to connect table mat to connection box) 4822 320 11306
earth cable (1M-„¦, to connect any product to mat or to connection box) 4822 320 11308
KIT ESD3 (combining all 6 prior products - small table mat) 4822 310 10671
wristband tester 4822 344 13999
AVAILABLE ESD PROTECTION EQUIPMENT
TECHANICAL SPECIFICATIONS
