Page 2
PCS 107 112
2-1
SERVICE TOOLS
TORX T10 screwdriver with shaftlength 150mm .........................................4822 395 50423
TORX screwdriver set SBC 163 ...............................................................4822 295 \
50145
Audio signal disc SBC 429 ........ ..............................................................4822 397 3\
0184
Playability test disc SBC 444 ...................................................................4822 \
397 30245
Test disc 5 (disc without errors ) +
Test disc 5A (disc with dropout errors, black spots and fingerprints)
SBC 426/426A .....................................................................482\
2 397 30096
Burn in test disc (65 min. 1kHz signal at -30 dB level without pause) .....4822 397 30155
Universal test cassette Fe SBC 420 ........................................................4822 397 30071
anti-static table mat large
small
anti-static wristband 4822 395 10223
connection box (3 press stud connections, 1MW )
extendible cable (2m, 2MWΩ , to connect wristband to connection box)
connecting cable (3m, 2M W , to connect table mat to connection box)
earth cable (1MW , to connect any product to mat or to connection box)
KIT ESD3 (combining all 6 prior products - small table mat)
wristband tester 4822 344 13999
AVAILABLE ESD PROTECTION EQUIPMENT
TECHNICAL SPECIFICATIONS
GE NE RAL
Mains voltage -/00/05/14 :230 V
-/01/11/16 :120 / 230 V
-/17 :120 V
Mains frequency -/00/05/14 :50 H z
-/01/11/16 :50 / 60 H z
-/17 :60 H z
Battery mains :9 V (R 20 x 6)
rem ote :3V (R03 x 2)
Pow er consum ption :5 W
Dimension (W x H x D ) :435 x 262 x 174 m m
Weight :3.4 Kg
AMPLIFIER
Output pow er mains :2 x 1.4 W
battery :2 x 2 W
Speaker im pedance :2 x 4 ohm
Frequency response :100 H z - 10 kH z (±3dB)
TUNE R - FM S ECTION
Tuning range :87.5 - 108 M Hz
IF frequency :10.7 M Hz ± 0.2 M Hz
Sensitivity : 18 dBf at 26dB S/N
Selectivity : 24 dB at 300kH z
IF rejection : 85 dB
Image rejection : 24 dB
TUNE R - AM S ECTION
Tuning range MW :531 - 1602 kH z
-/17 :530 - 1700 kH z
LW :153 -“ 279 kH z
IF frequency :468 kH z ± 3 kH z
Sensitivity MW :3200 µV/m at 26dB S/N
LW :5500 µV/m at 26dB S/N
Selectivity MW :22 dB
LW :29 dB
IF rejection MW :64 dB
LW :60 dB
Image rejection MW :32 dB
LW :38 dB
AUDIO CAS SETTE RE CORDE R
Number of tracks :1 stereo
Tape speed :4.76 cm /sec ± 3%
Wow & flutter :< 0.48 JIS U WTD
Fast w ind/rew ind C 60 :< 110 sec.
Frequency response P/B :125 - 8000 H z
S/N ratio : 40 dB
COMP ACT DIS C
Frequency response :100 H z - 10 kH z
S/N ratio :60 dB
Channel difference 1 kH z:2 dB
Channel crosstalk 1 kH z:40 dB
Laser w avelength :780 ± 20 nm
Laser light pow er :< 0.5 m W
