TECHNICAL SPECIFICATIONS
GENERAL
Mains voltage -/00C : 230 V
-/01 : 120 / 230 V
-/05/10 : 240V
-/17 : 120 V
Mains frequency
-/00C/05/10 : 50 Hz
-/01 : 50 / 60 Hz
-/17 : 60 Hz
Battery : 9 V (R14/UM -2/C-size x 6)
Power consumption : 12 W
Dimension (W x H x D) : 360 x 225 x 152mm
Weight : 2.3 Kg
AMPLIFIER
Output power mains : 2 x 1 W
battery : 2 x 1 W
Speaker impedance : 2 x 8 ohm
Frequency response : 100 Hz - 10 kHz (±3dB)
TUNER - FM SECTION
Tuning range : 87.5 - 108 MHz
IF frequency : 10.7 MHz ± 0.2 MHz
Sensitivity : 28 dBf at 26dB S/N
Selectivity : 24 dB at 300kHz
IF rejection : 65 dB
Image rejection : 26 dB
TUNER - AM SECTION
Tuning range : 512 - 1635 kHz
-/17 : 520 - 1700 kHz
IF frequency : 468 kHz ± 3 kHz
Sensitivity : 4000 µV/m at 26dB S/N
Selectivity : 20 dB
IF rejection : 70 dB
Image rejection : 32 dB
AUDIO CASSETTE RECORDER
Number of tracks : 1 stereo
Tape speed : 4.76 cm/sec ± 3%
Wow & flutter : < 0.48 JIS UWTD
Fast wind/rewind C60 : 130 sec.
Frequency response P/B : 125 - 8000 Hz
S/N ratio : -‰¥ 36 dB
COMPACT DISC
Frequency response : 100 Hz - 10 kHz
S/N ratio : 60 dB
Channel difference 1 kHz : 2 dB
Channel crosstalk 1 kHz : 40 dB
Laser wavelength : 780 ± 20 nm
Laser light power : < 0.5 mW
2 - 1
SERVICE TOOLS
Audio signal disc SBC 429.......................................................................4822 397 30184
Playability test disc SBC 444...................................................................4822 397 30245
Test disc 5(disc without errors ) +
Test disc 5A(disc with dropout errors, black spots and fingerprints)
SBC 426/426A.....................................................................4822 397 30096
Burn in test disc (65 min. 1kHz signal at -30 dB level without pause)
.....4822 397 30155
anti-static table mat
large 1200x650x1.25mm 4822 466 10953
small 600x650x1.25m 4822 466 10958
anti-static wristband4822 395 10223
connection box (3 press stud connections, 1M-„¦) 4822 320 11307
extendible cable (2m, 2M-„¦, to connect wristband to connection box) 4822 320 11305
connecting cable (3m, 2M-„¦, to connect table mat to connection box) 4822 320 11306
earth cable (1M-„¦, to connect any product to mat or to connection box) 4822 320 11308
KIT ESD3 (combining all 6 prior products - small table mat) 4822 310 10671
wristband tester4822 344 13999
AVAILABLE ESD PROTECTION EQUIPMENT
