Extracted text from Peavey USB SCARD Schematic (Ocr-read)
Page 1
Revision Description
Moved R26 from Dr to D+. Tied P6 to Gnd.
INDEX
DESCRIPTION
Note: All thru hole Resistors are 1/4 Watt unless otherwise indicated.
All SMT 1206 Resistors are 1/4 Watt.
All SMT 0805 Resistors are 1/10 Watt.
Note Capacitor Values are indicated as Follows:
val P = pF (picoFarads) val * 1O exp-12
val N = nF (nanoFarads) val * 10 exp-9 (1 N=1000pF, 100N=0.1uF)
val U = uF (microFarads) val * 10 exp»6
Patents:
Copyright Peavey Electronics Corporation 2005.
*Company Proprietary lntormation*
PEA/EV
P. O. Box 2898
Meridian, MS 39301
Sound card tor Mixers
USB_SCARD
Project Number:
Eng: I Release Date:
Bl Sheet 1 of 2 lSaved: 17772005157
