Page 1
Revision Description
INDEX
DESCRIPTION
Note: All thru hole Resistors are 1/4 Watt unless otherwise indicated.
All SMT 1206 Resistors are 1/4 Watt.
All SMT 0805 Resistors are 1/10 Watt.
Note Capacitor Values are indicated as Follows:
val P = pF (picoFarads) val * 1O exp-12
val N = nF (nanoFarads) val * 10 exp-9 (1 N=1000pF, 100N=0.1uF)
val U = uF (microFarads) val * 10 exp»6
Patents:
Copyright Peavey Electronics Corporation 2008.
*Company Proprietary lntormation*
PEAVEV
P. O. Box 2898
Meridian, MS 39301
PV6
Project Number:
Eng: I Release Date:
Bl Sheet 1 of 10 ISaVed: 12777200971358
