Peavey PR 12D PR 15D Schematics
This is the 12 pages manual for Peavey PR 12D PR 15D Schematics.
Read or download the pdf for free.
If you want to contribute, please mail your pdfs to info@audioservicemanuals.com.
Extracted text from Peavey PR 12D PR 15D Schematics (Ocr-read)
Page 1
A c
REV Eng Date: Revision Description ECN#
A
B
C
D
E
F
INDEX
SHEET DESCRIPTION
Note: All thru hole Resistors are 1/4 Watt unless otherwise indicated.
All SMT 1206 Resistors are 1/4 Watt.
All SMT 0805 Resistors are 1/10 Watt.
Note Capacitor Values are indicated as Follows:
val P = pF (picoFarads) val * 1O exp-12
val N = nF (nanoFarads) val * 10 exp»9 (1 N=1000pF, 100N=0.1uF)
val U = uF (microFarads) val * 10 exp»6
Patents:
Copyright Peavey Electronics Corporation 2008.
*Company Proprietary Information*
/\ /
/ j/
P. O. Box 2898
Meridian, MS 39301
PR_CLASS_D_I
Project Number:
Eng: Release Date:
Bi Sheet 1 of 5 Saved: 27297200871331
