Page 1
2
Introduction
Congratulations on your purchase of your PAL-245 Precision Architectural Loudspeaker
system and thank you for choosing Parasound. The PAL-245 Precision Architectural
Loudspeakers were developed using the finest loudspeaker and crossover components
available. Countless hours of computer modeling were spent to insure accurate audio
reproduction in a variety of installations where placement compromises must sometimes be
made. The PAL-245 Precision Architectural Loudspeakers mounted in your walls deliver
the high-fidelity audio reproduction you have come to expect from high-end loudspeakers
in a cabinet. Please take a few minutes to read these instructions thoroughly to make the
installation easier and insure the best performance of your new PAL-245 Precision
Architectural Loudspeakers.
Unpacking and Inspection
Carefully unpack your PAL-245 loudspeakers locate the enclosed accessories:
Qty Description
2 PAL-245 baffle and loudspeaker assembly
2 Metal grilles
2 Foam grille inserts
2 Paint Shields
Be sure to carefully inspect the speakers for any signs of shipping damage. If you believe
you notice any, contact your Parasound Dealer immediately.
Precautions
If you have any doubts about your ability to properly install in-wall loudspeakers, you should
consider the services of a custom installer. If you plan to install them yourself, always use
good quality tools to save time and make the installation go more smoothly.
The PAL-245 Precision Architectural Loudspeakers mount into standard 4 inch (or greater)
stud depth walls. Determine the final location of both left and right speakers before cutting
any holes since changes to one speaker may affect the other either aesthetically or acoustically.
Look for pipes, wiring or any other conflicting material that might be damaged before
beginning the installation.
Prewiring
Before you purchase loudspeaker wire, check local building codes to make sure that the
wire is rated to comply with applicable local safety codes such as UL or CL-2. Use only
stranded wire no thinner than AWG 16. For runs longer than 100 feet, we recommend
minimum of AWG 14. When pulling wire, take care not to pull the wire too fast to prevent
stretching the wire or scorching the insulation from friction. Leave 2 to 3 feet of excess
loudspeaker wire at both ends; it is easier to trim off excess wire than to splice additional
wire. When securing the wire inside the walls, be careful not to pierce the insulation with
nails or staples.
Page 2
3
For best performance and easier troubleshooting, always Òhome runÓ wiring when installing
multiple speakers rather than connecting from one speaker to the next. When connecting
multiple speakers, make sure that the power amplifier is capable of adequately driving the
combined impedance of the speakers. If not, you may need additional amplifiers or an
impedance protection device that are often built into loudspeaker selection boxes.
Installing the PAL-245 Precision Architectural Loudspeakers
1. Confirm that there is at least 1 1/2" of clearance between each edge of the planned
cutout and adjacent studs or joints.
2. Fasten the supplied cardboard template to the wall or ceiling with tape or thumbtacks.
Check again for equal distance of both speakers from the ceiling or floor.
3. Use a level or the included templateÕs self-leveling feature to insure the cutout will be
level.
4. Trace around the perimeter of the template.
5. Before making the final cutout, make a small 6-inch square Òtest cutoutÓ in the center of
the penciled outline. Reach inside the test hole to verify that there are no obstructions in
the way of your planned cutout.
6. Before cutting the hole, first score the drywall with a razor knife and use a keyhole saw
to complete the cut. Remove debris from the edge of the hole.
7. Secure the speaker wire to a stud near the cutout so its weight will not tug on the terminals
of the speaker after it is connected. This also keeps the wire from dropping behind the
wall before you can connect it.
8. Push down the tab on the speaker terminals and insert the speaker wire into the connector.
9. Insert the PAL-245 into the cutout to make sure it fits easily without forcing.
10. Evenly tighten the mounting screws on the bezel. The mounting Òswing-armsÓ (also
known as mounting ÒdogsÓ) will automatically swing out 90 degrees. After they swing
out, the arms then clamp against the drywall from behind the wall. Avoid using excessive
force to prevent deforming the drywall or cracking the speakerÕs mounting frame.
11. We recommend that you add a ÒblanketÓ of sound absorbing material such as ceiling
insulation behind the woofer to reduce sound transmission into the adjoining room.
Additionally, any sound leakage from behind the molded frame can be blocked with
foam weather-stripping directly behind the plastic speaker bezel.
Pre-Drilled Hole for Infrared Receivers
The PAL-245 has a 1/2" hole in the bezel to accommodate an infrared receiver such as the
Xantech Video Link model 490. The hole can be easily accessed by removing the rubber
bushing from the rear of the bezel. If you plan to hide an infrared receiver behind the
loudspeaker grille, be sure to pre-wire a three conductor control wire along with the speaker
wire.
