Page 1
2
Command
Input Aux-Phono
Input CD
Input Tuner
Input TapeString ASCII 1 17 1 36
1 17 1 37
1 17 1 38
1 17 1 39String Hexadecimal 31,20,31,37,20,31,20,33,36
31,20,31,37,20,31,20,33,37
31,20,31,37,20,31,20,33,38
31,20,31,37,20,31,20,33,39
Balance Right 1 17 1 72 31,20,31,37,20,31,20,37,32
Balance Left 1 17 1 71 31,20,31,37,20,31,20,37,31
Treble Up 1 17 1 74 31,20,31,37,20,31,20,37,34
Treble Down 1 17 1 73 31,20,31,37,20,31,20,37,33
Bass Up 1 17 1 76 31,20,31,37,20,31,20,37,36
Bass Down
Next Source1 17 1 75
1 17 1 7031,20,31,37,20,31,20,37,35
31,20,31,37,20,31,20,37,30
Please Note: stands for Carriage Return, the Hex Code is 0D. A space in
Hex is 20, a space in ASCII is just a blank space (as shown above).
-™¦Rx Format (Feedback):
Response information is in plain human readable text when viewed in ASCII Format.
Feedback mimics what is shown on front panel display of actual Preamp. Please note that
units with serial numbers below 02101 do not send any feedback.
An example when input is CD and Left & Right Volume is set to 55:
205,),000,246,205,000, CD, L, 55, 55, R, 000,200
--------HEADER-------- --Input-- ----Volume--- --End---
