CSE 6.1 Center Surround Expander Features
Works with any 5.1 Surround Processor or Receiver
6.1 Information Present Indicator
Fully Remote Controllable
Dual Center Surround Outputs
Rear Subwoofer Output Jack
Adjustable Rear Subwoofer Low-Pass Filter
Calibration Circuitry For Setting Center Surround Level
LS, RS Unity Gain Setting Makes Level Setting Easy
Special Output Jacks for Overhead Ambient Effects
External Infrared Remote Control Input
Gold Plated RCA Jacks
External 12 V Power Supply
Unique Circle Surround
® Matrix Processing
Table of Contents
Front, Rear Panel and Remote Control Drawings ................... 4
Introduction ....................... 6
Unpacking ...................... 6
Installation and Rack Mounting ................. 6
About Rear Center Surround Channel Technology .......... 7
Making Connections to Your CSE 6.1 .................. 9
Setting up Your CSE 6.1 Center Surround Expander .......... 10
Operating Your CSE 6.1 ........................ 12
Maintaining Your Parasound CSE 6.1 ..................... 13
CSE 6.1 Specifications .......................... 14
Page 2
3
Important Safety Instructions
Save these instructions for future use
This triangle alerts you to the dangerous voltages inside that may be a shock hazard.
This triangle alerts you to important operating and maintenance instructions in this manual.
üAlways use with the correct line voltage. Refer to the manufacturers operating instructions for power
requirements. Be advised that different operating voltages may require the use of a different line cord and/
or attachment plug.
üDo not install the unit in an unventilated rack, or directly above heat producing equipment such as power
amplifiers. Observe the maximum ambient operating temperature listed in the product specification.
üSlots and opening on the case are provided for ventilation; to ensure reliable operation and prevent it from
overheating, these openings must not be blocked or covered. Never push objects of any kind through the
ventilation slots. Never spill a liquid of any kind on the unit.
üNever attach audio power amplifier outputs directly to any of the units connectors.
üTo prevent shock or fire hazard, do not expose the unit to rain or moisture, or operate it where it will be
exposed to water.
üDo not attempt to operate the unit if it has been dropped, damaged, exposed to liquids, or if it exhibits a
distinct change in performance indicating the need for service.
üThis unit should only be opened by qualified service personnel. Removing covers will expose you to
hazardous voltages.
üAdhere to all warnings on the unit and in the operating instructions.
üTake precautions not to defeat the grounding or polarization of the units power cord.
üDo not overload wall outlet, extension cords or integral convenience receptacles, as this can result in a risk
of fire or electrical shock.
üRoute power supply cords so that they are not likely to be walked on or pinched by items placed on or
against them, paying particular attention to cords at plugs, convenience receptacles, and the point at which
they exit from the unit.
üThe unit should be cleaned only as recommended.
Communications Notice
This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in
strict accordance with the manufacturers instructions, may cause interference to radio and television reception.
It has been type tested and found to comply with the limits for a Class B computing device in accordance with
the specifications in Subpart J of Part 15 of FCC Rules, which are designated to provide reasonable protection
against such interference in a residential installation. However, there is no guarantee that interference will not
occur in a particular installation. It this equipment does cause interference to radio or television reception,
which can be determined by turning the equipment OFF and ON, the user is encouraged to try to correct the
interference by one or more of the following measures:
üReorient the television receiving antenna
üRelocate the AVC-2500 away from the television
üPlug the AVC-2500 into a different AC outlet so that the AVC-2500 and television are on different branch
circuits.
If necessary, the user should consult the dealer or an experienced radio/television technician for additional
suggestions. The user may find the following booklet prepared by the Federal Communications Commission
helpful: How to identify and Resolve Radio/TV Interference Problems. This booklet is available from the
U.S. Government printing office, Washington, DC 20402, Stock No.004-000-00345-4.
Le présent appareil numénque n émet pan de bruits radioélectriques dépassant len limites applicables aux
appareils numériques de la class B prescrites dans le Réglement sur le brouillage radloélectrique édicté par le
ministère des Communications du Canada.
