Page 1
2
TABLE OF CONTENTS
PA G E PA G E
1Warning--------------------------------------------------------------3
1.1. Caution for AC Mains Lead(For GH) ------------------3
2 Service Navigation------------------------------------------------4
2.1. About Lead Free Solder (PbF)--------------------------4
3 Specifications------------------------------------------------------4
4 Location of Controls and Components--------------------5
4.1. Accessories -------------------------------------------------- 5
4.2. Location of Controls --------------------------------------- 5
5 Service Mode-------------------------------------------------------6
5.1. Before Entering The Service Mode --------------------6
5.2. Entering The Service Mode -----------------------------6
5.3. SERVICE 1LCD Display Mode Switching------------8
5.4. SERVICE 2Device Key Serial NumberDisplay ----- 8
5.5. SERVICE 3Battery Capacity Display and
Control Button Operation Check ----------------------- 9
5.6. SERVICE 4Model and Region Display ------------- 10
5.7. SERVICE 8Card Recognition Operation
Check ------------------------------------------------------- 10
5.8. SERVICE 9Audio Playback Check ------------------ 11
5.9. SERVICE 10Voice Playback Check ----------------- 11
5.10. SERVICE 11Voice Recording Check---------------- 12
5.11. SERVICE 12FM Recording Check ------------------ 13
5.12. SERVICE 13Device Check ---------------------------- 14
5.13. MODELModel and Region Setting------------------- 14
5.14. Error Code Table ----------------------------------------- 15
6 Service Fixture & Tools---------------------------------------18
6.1. Service Position ------------------------------------------ 18
7 Disassembly and Assembly Instructions---------------19
7.1. Removal of the front cabinet unit and rear
cabinet unit------------------------------------------------- 19
7.2. Removal of the Sub P.C.B. ---------------------------- 20
7.3. Removal of the LCD ------------------------------------- 20
7.4. Removal of the Main P.C.B. --------------------------- 20
