Before using 2 RQT5706 Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully. These operating instructions are applicable to the following system. System SC-PM11 Main unitSA-PM11 SpeakersSB-PM11 Before using Supplied accessories.............................................. 2 IMPORTANT SAFETY INSTRUCTIONS................... 4 Placement of speakers............................................ 5 Concerning the remote control.............................. 5 Battery installation.......................................................... 5 Correct method of use................................................... 5 Connections............................................................. 6 Basic connections (for supplied accessories)................. 6 Optional antenna connections........................................ 7 External unit connection................................................. 7 Front panel controls................................................ 8 Setting the time........................................................ 9 Turning the demo function off................................ 9 Auto-off function...................................................... 9 Compact disc operations Concerning compact discs................................... 10 Listening to compact discs.................................. 11 Direct access play........................................................ 12 Repeat play.................................................................. 12 Random play................................................................ 12 Program play............................................................... 13 To listen to special CDs and tracks (CD Manager function).............................................. 14 Radio operations Listening to radio broadcasts............................... 15 Presetting radio broadcasts................................. 16 Cassette deck operations Listening to tapes.................................................. 17 The model number and serial number of this product can be found on either the back or the bottom of the unit. Please note them in the space provided below and keep for future reference. MODEL NUMBER SERIAL NUMBER User memo: DATE OF PURCHASE DEALER NAME DEALER ADDRESS TELEPHONE NUMBER CAUTION! THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL. CAUTION: TO PREVENT ELECTRIC SHOCK MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. Table of contents Please check and identify the supplied accessories. Use numbers indicated in parentheses when asking for replacement parts. (Only for U.S.A.) To order accessories contact 1-800-332-5368 or web site (http://www.panasonic.com). AC power supply cord . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pc. (RJA0065-A) FM indoor antenna (RSA0006-L) . . . . . . . . . . . . . . . . . 1 pc. Supplied accessories CAUTION! DO NOT INSTALL, OR PLACE THIS UNIT, IN A BOOKCASE, BUILT-IN CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE UNIT IS WELL VENTILATED. TO PREVENT RISK OF ELECTRIC SHOCK OR FIRE HAZARD DUE TO OVERHEATING, ENSURE THAT CURTAINS AND ANY OTHER MATERIALS DO NOT OBSTRUCT THE VENTILATION VENTS. WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT DAMAGE, DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS.

Page 2

Before using 3 RQT5706 AM loop antenna (RSA0033A)................... 1 pc. Remote control transmitter.............................................. 1 pc. (N2QAGB000007) Batteries........... 2 pcs. (R6, AA, UM-3) The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE SCREWS. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Recording operations Before recording.................................................... 18 Recording the radio............................................... 19 Recording discs..................................................... 20 Recording with CD Manager........................................ 20 Other functions Using the built-in sound quality/ sound field settings.......................................... 21 Enhancing the sound quality................................ 21 To mute the volume.............................................. 21 Timer operations Using the timer...................................................... 22 Using the play/record timer.......................................... 22 Using the sleep timer................................................... 24 Reference Using an external unit........................................... 24 Troubleshooting guide.......................................... 25 Servicenter List (U.S.A.)........................................ 26 Warranty (U.S.A.)................................................... 27 Specifications.........................................Back Cover Maintenance............................................Back Cover Product Service......................................Back Cover THE FOLLOWING APPLIES ONLY IN THE U.S.A.: CAUTION: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that inter- ference will not occur in a particular installation. If this equip- ment does cause harmful interference to radio or television reception, which can be determined by turning the equip- ment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ¡Reorient or relocate the receiving antenna. ¡Increase the separation between the equipment and re- ceiver. ¡Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ¡Consult the dealer or an experienced radio/TV technician for help. Any unauthorized changes or modifications to this equip- ment would void the users authority to operate this device. This device complies with Part 15 of the FCC Rules. Opera- tion is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
