Before using 2 RQT6243 Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully. These operating instructions are applicable to the following system. SystemSC-AK600 Main unitSA-AK600 FrontSB-AK600 Speakers CenterSB-PC93 SurroundSB-PS90 The model number and serial number of this product can be found on either the back or the bottom of the unit. Please note them in the space provided below and keep for future reference. MODEL NUMBER SERIAL NUMBER Main unit SA-AK600 Front speakers SB-AK600 Center speaker SB-PC93 Surround speakers SB-PS90 CAUTION! THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL. Table of contents WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT DAMAGE, DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS. CAUTION! DO NOT INSTALL, OR PLACE THIS UNIT, IN A BOOKCASE, BUILT-IN CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE UNIT IS WELL VENTILATED. TO PREVENT RISK OF ELECTRIC SHOCK OR FIRE HAZARD DUE TO OVERHEATING, ENSURE THAT CURTAINS AND ANY OTHER MATERIALS DO NOT OBSTRUCT THE VENTILATION VENTS. CAUTION: TO PREVENT ELECTRIC SHOCK MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. User memo: DATE OF PURCHASE DEALER NAME DEALER ADDRESS TELEPHONE NUMBER Before using Supplied accessories.............................................. 3 Listening caution..................................................... 3 IMPORTANT SAFETY INSTRUCTIONS................... 4 Installation ................................................................ 5 Connections............................................................. 6 Location of controls................................................ 7 The remote control.................................................. 8 Disc operations Playing discs............................................................ 9 Starting play from a specific track................................ 10 Repeat play.................................................................. 10 Program play............................................................... 11 Other modes of play (CD Play Mode function)............. 12 Radio operations The radio: manual tuning...................................... 13 The radio: preset tuning........................................ 14 Tape operations Cassette tapes....................................................... 15 Recording operations Before recording.................................................... 16 Recording discs..................................................... 17 Recording the radio............................................... 17 Sound quality/sound field operations Using the built-in sound quality settings............. 18 Enhancing the sound quality................................ 18 Adjusting the bass................................................ 18 Enjoying surround sound..................................... 19 DOLBY DIGITAL.......................................................... 20 DOLBY PRO LOGIC.................................................... 20

Page 2

Before using 3 RQT6243 Please check and identify the supplied accessories. Use numbers indicated in parentheses when asking for replacement parts. (Only for U.S.A.) To order accessories contact 1-800-332-5368 or web site (http://www.panasonic.com). AC power supply cord..................................................... 1 pc. (RJA0065-1D) FM indoor antenna ... 1 pc. (RSA0006-J) Supplied accessories AM loop antenna.... 1 pc. (RSA0033-1) Remote control transmitter.............. 1 pc. (N2QAGB000018) Remote control batteries................ 2 pcs. R6, AA, UM-3 THE FOLLOWING APPLIES ONLY IN THE U.S.A.: CAUTION:This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that inter- ference will not occur in a particular installation. If this equip- ment does cause harmful interference to radio or television reception, which can be determined by turning the equip- ment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ¡Reorient or relocate the receiving antenna. ¡Increase the separation between the equipment and re- ceiver. ¡Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ¡Consult the dealer or an experienced radio/TV technician for help. Any unauthorized changes or modifications to this equip- ment would void the users authority to operate this device. This device complies with Part 15 of the FCC Rules. Opera- tion is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Timer and other operations Convenient functions............................................ 22 Using headphones (not included)........................ 22 Turning DEMO off.................................................. 23 Auto-off function.................................................... 23 Setting the time...................................................... 23 Using the timers.................................................... 24 Using the play/record timer.......................................... 24 Using the sleep timer................................................... 25 Using other equipment.......................................... 26 Connecting other equipment........................................ 26 Optional antenna connections...................................... 26 Listening to an external digital source.......................... 27 Listening to an external analog source........................ 27 Recording an external source...................................... 27 Reference Troubleshooting guide.......................................... 28 Servicenter List (ONLY FOR U.S.A.).................... 29 Warranty (ONLY FOR U.S.A.)................................ 30 Product Service..................................................... 30 About discs............................................................ 31 Maintenance........................................................... 31 Specifications.........................................Back Cover Selecting fine audio equipment such as the unit youve just pur- chased is only the start of your musical enjoyment. Now its time to consider how you can maximize the fun and excitement your equip- ment offers. This manufacturer and the Electronic Industries Associ- ations Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying blaring or distortion-and, most importantly, without affecting your sensitive hearing. We recommend you to avoid prolonged exposure to excessive noise. Sound can be deceiving. Over time your hearing comfort level adapts to higher volumes of sound. So what sounds normal can actually be loud and harmful to your hearing. Guard against this by setting your equipment at a safe level BEFORE your hearing adapts. To establish a safe level: -Start your volume control at a low setting. -Slowly increase the sound until you can hear it comfortably and clearly, and without distortion. Once you have established a comfortable sound level: -Set the dial and leave it there. Taking a minute to do this now will help to prevent hearing damage or loss in the future. After all, we want you listening for a lifetime. Listening caution
