1 Service Navigation
1.1. System Information (SB-AKX34PN-K)
SB-AKX34PN-K is use for the following main models:
SC-AKX34PH-K
SC-AKX34PN-K
SC-AKX34PR-K
1.2. Front Speakers (SB-AKX34PN-K)
The illustrations for the speakers will be described in this manual.
- Disassembly and Assembly Instructions
- Wiring Connection Diagram
- Exploded View
- Replacement Parts List
Page 2
3
2 Specifications
Front Speakers (SB-AKX34PN-K)
Ty p e2 way, 2 speaker system (Bass reflex)
Speaker unit(s)
Woofer 20 cm Cone type
Tweeter 6 cm Cone type
Impedance4Ω
Output sound pressure87 dB/W (1 m)
Frequency range50 Hz to 21 kHz (-16 dB)
75 Hz to 20 kHz (-10 dB)
Dimensions (W x H x D)250 mm x 429 mm x 226 mm
Mass4 kg
Notes:
1. Specifications are subject to change without notice. Mass and
dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum ana-
lyzer.
