Page 1
1 System Combination
Note :
The tables below show the breakdown for speaker combinations used in main unit systems.
1.1. System Breakdown
System SC-AK860GCPK
Music center SA-AK860GCPK
Front speakers SB-PF960GCPK
Active subwoofer SB-WAK860GCPK
Main System SF-AK960GCPK
Music center SA-AK960GCPK
Front speakers SB-PF960GCPK
Speaker system SB-AK960GCPK
Surround speakers SB-PS960GCPK
Subwoofer SB-WAK960GCPK
Active subwoofer SB-WAK860GCPK
1.2. Packaging information (SB-AK960GCPK)
Note: For more information on the complete packaging condition for speakers in SB-AK960 GCPK, please refer to section 4.3 in
service manual of SB-PS960GC -K (Order no. MD070 7025C E).
2
SB-WAK860GC P
Page 2
2 Operation Procedures
2.1. Remote Control Key Buttons Operation
2.2. Features of subwoofer
3
SB-WAK860GC P
