Page 1
RQT7694
2
Accessoires fournis
Vérifier la présence et létat des pièces et
accessoires suivants.
Lors de la commande de pièces de rechange,
utiliser les numéros indiqués entre parenthèses.
SB-FS70
Câbles de raccordement (long: 10 m) (32,8 pi) . . . . . . . . . . . 2
(REE1203C)
Câbles de raccordement (court: 4 m) (13,1 pi) . . . . . . . . . . . . 2
(REE1203A)
Stabilisateur assemblé . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(RYQ0526-S)
Socle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(RYQ0521-S)
Pieds en caoutchouc . . . . . . . . . . . . . . . . . . . . . . . 1 feuille (24)
(RFA2645A)
(pièce de rechange - 6 par feuille)
Vis pour base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
(XTB4+30JFZ)
Collier en nylon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(RMR1503-W)
Vis pour collier en nylon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(XTB3+8JFN)
SB-PC70
Câbles de raccordement (court: 4 m) (13,1 pi) . . . . . . . . . . . . 1
(REE1203A)
Pieds pour enceintes . . . . . . . . . . . . . . . . . . . . . . . . 1 feuille (4)
(RFA0631A-K)
SB-WA70
Cordon dalimentation c.a. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
(K2CB2CB00006)
Nota
Le cordon dalimentation fourni est pour utilisation exclusive avec
cet appareil. Ne pas Iutiliser avec un autre appareil.
Câble de raccordement monaural (5 m) (16,4 pi) . . . . . . . . . . 1
(RJL1P015B50)
Supplied accessories
Please check and identify the supplied accesso-
ries.
Use numbers indicated in parentheses when ask-
ing for replacement parts.
In U.S.A. to order accessories, refer to Ac-
cessory Purchases on back cover.
SB-FS70
Speaker cables (long: 10 m) (32.8 ft) . . . . . . . . . . . . . . . . . . . 2
(REE1203C)
Speaker cables (short: 4 m) (13.1 ft) . . . . . . . . . . . . . . . . . . . 2
(REE1203A)
Assembled stabilizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(RYQ0526-S)
Base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(RYQ0521-S)
Rubber pads . . . . . . . . . . . . . . . . . . . . . . . . . . 1 sheet (24 feet)
(RFA2645A) (6 feet per sheet)
Screw for base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
(XTB4+30JFZ)
Nylon clamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(RMR1503-W)
Screw for nylon clamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(XTB3+8JFN)
SB-PC70
Speaker cables (short: 4 m) (13.1 ft) . . . . . . . . . . . . . . . . . . . 1
(REE1203A)
Speaker feet . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 sheet (4 feet)
(RFA0631A-K)
SB-WA70
AC power supply cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
(K2CB2CB00006)
Note
The included AC power supply cord is for use with this unit only.
Do not use it with other equipment.
Monaural connection cable (5 m) (16.4 ft) . . . . . . . . . . . . . . . 1
(RJL1P015B50)
Dear customer
Thank you for purchasing this product.
For optimum performance and safety, please read these instructions
carefully.
Cher client
Nous vous remercions davoir arrêté votre choix sur cet appareil.
Pour en tirer un rendement optimal, lire attentivement le présent
manuel.
Speaker system Speaker
SB-FS70Front, SurroundSB-FS70 X 4
SB-CW70CenterSB-PC70 X 1
Active subwooferSB-WA70 X 1
Modèle Enceinte
SB-FS70Avant, ambiophoniquesSB-FS70 X 4
SB-CW70Canal centreSB-PC70 X 1
Extrêmes-graves avec ampliSB-WA70 X 1
Page 2
RQT7694
3
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR PRODUCT DAMAGE, DO NOT
EXPOSE THIS APPARATUS TO RAIN,
MOISTURE, DRIPPING OR SPLASHING AND
THAT NO OBJECTS FILLED WITH LIQUIDS,
SUCH AS VASES, SHALL BE PLACED ON THE
APPARATUS.
CAUTION!
DO NOT INSTALL OR PLACE THIS UNIT IN A
BOOKCASE, BUILT-IN CABINET OR IN
ANOTHER CONFINED SPACE. ENSURE THE
UNIT IS WELL VENTILATED. TO PREVENT
RISK OF ELECTRIC SHOCK OR FIRE HAZARD
DUE TO OVERHEATING, ENSURE THAT
CURTAINS AND ANY OTHER MATERIALS DO
NOT OBSTRUCT THE VENTILATION VENTS.
MISE EN GARDE:
AFIN DE PRÉVENIR TOUT RISQUE DINCENDIE
OU DE CHOCS ÉLECTRIQUES, AINSI QUE
TOUT DOMMAGE Ã- LAPPAREIL, NE PAS
LEXPOSER Ã- LA PLUIE, Ã- DES
ÉCLABOUSSURES OU Ã- UNE HUMIDITÉ
EXCESSIVE. ÉVITER ÉGALEMENT DE PLACER
DES CONTENANTS AVEC DU LIQUIDE, TEL UN
VASE, SUR LAPPAREIL.
ATTENTION!
NE PAS INSTALLER CET APPAREIL DANS UNE
BIBLIOTHÈQUE, UNE ARMOIRE OU TOUT
AUTRE ESPACE CONFINÉ. SASSURER QUE
LA VENTILATION DE LAPPAREIL EST
ADÉQUATE. AFIN DÉVITER TOUT RISQUE DE
CHOC ÉLECTRIQUE OU DINCENDIE DÛ Ã- UN
SURCHAUFFEMENT, SASSURER QUE
RIDEAUX OU TOUT OBJET QUELCONQUE NE
BOUCHENT LES ÉVENTS DAÉRATION DE
LAPPAREIL.
Although the AC power switch is in the OFF position, the
unit is not completely disconnected from the mains. Remove
the plug from the main electrical outlet if you will not be
using the unit for an extended period of time. Place the unit
so the plug can be easily removed.
Même si linterrupteur est à la position OFF, lappareil nest
pas entièrement déconnecté de la source dalimentation.
Débrancher la fiche de la prise secteur si lappareil ne sera
pas utilisé pendant une période prolongée. Placer lappareil
de façon que la fiche soit facilement accessible.
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated dangerous voltage
within the products enclosure that may be of suffi-
cient magnitude to constitute a risk of electric shock
to persons.
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE SCREWS.
NO USER-SERVICEABLE PARTS
INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ATTENTION
RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
ATTENTION: AFIN DE PRÉVENIR LE RISQUE
DE CHOCS ÉLECTRIQUES, NE
PAS RETIRER LES VIS.
TOUTE RÉPARATION DEVRAIT
ÊTRE CONFIÉE Ã- UN
PERSONNEL QUALIFIÉ.
Le point dexclamation dans un triangle équilatéral
indique que le manuel dutilisation inclus avec
lappareil contient dimportantes recommandations
quant au fonctionnement et à lentretien de ce
dernier. Le symbole de léclair dans un triangle équilatéral
indique la présence dune tension suffisamment
élevée pour engendrer un risque de chocs
électriques.
CAUTION (SB-FS70):
Do not stand on the base and shake the speaker. Be cau-
tious when children are near (see page 7).
ATTENTION (SB-FS70) :
Ne pas se tenir debout sur le socle ni secouer lenceinte.
Surveiller de près les enfants lorsquils sapprochent de
lenceinte (voir page 7).
