RQT8572
2
Dear customer
Thank you for purchasing this product.
For optimum performance and safety, please read these instructions
carefully.
Cher client
Nous vous remercions davoir arrêté votre choix sur cet appareil.
Pour en tirer un rendement optimal, lire attentivement le présent
manuel.
Speaker system Speaker
Front, SurroundSB-FS100 X 4
SB-TP100CenterSB-PC100 X 1
Active subwooferSB-WA101 X 1
Accessoires fournis
Vérifier la présence et létat des pièces et
accessoires suivants.
Lors de la commande de pièces de rechange,
utiliser les numéros indiqués entre parenthèses.
à partir de janvier 2006
SB-FS100
Câbles de raccordement (long: 10 m) (32,8 pi) . . . 2
(REE1247C)
Câbles de raccordement (court: 4 m) (13,1 pi) . . . 2
(REE1247A)
Socle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(RYQ0596-S)
Vis pour socle . . . . . . . . . . . . . . . . . . . . . . . . . . 16
(RHD40028)
Clé hexagonale . . . . . . . . . . . . . . . . . . . . . . . . . . 1
(RHQ0091-K)
Couvercle inférieur . . . . . . . . . . . . . . . . . . . . . . . 4
(RGK1982-S)
Entretoise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
(RKA0182-H)
Collier en nylon . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(RMR1503-W)
Vis pour collier en nylon . . . . . . . . . . . . . . . . . . . 4
(XTW3+10JFN)
SB-PC100
Câbles de raccordement (court: 4 m) (13,1 pi) . . . 1
(REE1247A)
Pieds pour enceintes . . . . . . . . . . . 1 feuille (4 pi)
(RFA1388A)
SB-WA101
Cordon dalimentation . . . . . . . . . . . . . . . . . . . . . 1
(K2CB2CB00018)
Le cordon dalimentation fourni est pour utilisation exclusive avec
cet appareil. Ne pas Iutiliser avec un autre appareil.
Câble de raccordement monaural (5 m) (16,4 pi) . . 1
(RJL1P015B50)
Supplied accessories
Please check and identify the supplied accesso-
ries.
Use numbers indicated in parentheses when ask-
ing for replacement parts. As of January 2006
In U.S.A. to order accessories, refer to Ac-
cessory Purchases on page 14.
SB-FS100 Speaker cables (long: 10 m) (32.8 ft) . . . . . . . . . 2
(REE1247C)
Speaker cables (short: 4 m) (13.1 ft) . . . . . . . . . 2
(REE1247A)
Stand base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(RYQ0596-S)
Bolt for stand base . . . . . . . . . . . . . . . . . . . . . . 16
(RHD40028)
Hexagonal wrench . . . . . . . . . . . . . . . . . . . . . . . 1
(RHQ0091-K)
Bottom cover . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(RGK1982-S)
Spacer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
(RKA0182-H)
Nylon clamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(RMR1503-W)
Screw for nylon clamp . . . . . . . . . . . . . . . . . . . . 4
(XTW3+10JFN)
SB-PC100
Speaker cables (short: 4 m) (13.1 ft) . . . . . . . . . 1
(REE1247A)
Speaker feet . . . . . . . . . . . . . . . . . 1 sheet (4 feet)
(RFA1388A)
SB-WA101
AC power supply cord . . . . . . . . . . . . . . . . . . . . 1
(K2CB2CB00018)
The included AC power supply cord is for use with this unit only.
Do not use it with other equipment.
Monaural connection cable (5 m) (16.4 ft) . . . . . 1
(RJL1P015B50)
Modèle Enceinte
Avant, ambiophoniquesSB-FS100 X 4
SB-TP100Canal centralSB-PC100 X 1
Enceinte dextrêmes-graves avec amplificateur SB-WA101 X 1
User memo:
The model number and serial number of this product can be found
on either the back or the bottom of the unit.
Please note them in the space provided below and keep for future reference.
MODEL NUMBER SERIAL NUMBER SB-FS100
SB-PC100SB-WA101
DATE OF PURCHASEDEALER NAMEDEALER ADDRESS
TELEPHONE NUMBER
Homologation:
Il est recommandé de noter, dans lespace prévu ci-dessous, le numéro
de modèle et le numéro de série inscrits à larrière, ou sous le fond de
lappareil, et de conserver ce manuel pour référence ultérieure.
NUMÉRO DE MODÈLE NUMÉRO DE SÉRIE SB-FS100SB-PC100SB-WA101
DATE DACHATDÉTAILLANTADRESSE DU DÉTAILLANT
NO DE TÉLÉPHONE
