2 Assembling and Disassembling
ATTENTION SERVICER
Some chassis components may have sharp edges. Be careful when disassembling and servicing.
1. This section describes procedures for checking the operation and replacing the main components.
2. For reassembly after operation checks or replacement, reverse the respective procedures.
Specia l reassembly procedures are described only when required.
3. Select items from the following index when checks or replacement are required.
4. Refer to the Parts No. on the page of Parts Locatio n and Replac ement Parts List (Section 5), if necessary.
Below is the list of disassembly sections
Disasse mbly of Rear cabinet assembly
Disasse mbly of Woofer 1 (SP1)
Disasse mbly of Woofer 2 (SP1)
