1 System Combination
1.1. System Breakdown
Note :
The diagrams below show the breakdown for speaker combinations used in main unit systems.
SB-PT750 P-K consists of SB-HF750P-K (x2), SB-HS750P-K (x2), SB-HC750P-K (x1) &SB-HW750P-K (x1)
2
SB-HF750 P
Page 2
2 Assembling and Disassembling
ATTENTION SERVICER
Some chassis components may have sharp edges. Be careful when disassembling and servicing.
1. This section describes procedures for checking the operation of the major printed circuit boards and replacing the main
components.
2. For reassembly after operation checks or replacement, reverse the respective procedures.
Specia l reassembly procedures are described only when required.
3. Select items from the followingindex when checks or replacement are required.
4. Refer to the Parts No. on the page of Parts Location and Replac ement Parts List (Section 6), if necessary.
Below is the list of disassembly sections
·
Disasse mbly of Rear cabinet assembly
·
Disasse mbly of Woofer
2.1. Disassembly flow chart
The following chart is the procedure for disassembling the casing and inside parts for internal inspection when carrying out the
servicing.
To assemble the unit, reverse the steps shown in the chart as below.
3
SB-HF750 P
