Extracted text from panasonic sb hc 550 g service manual (Ocr-read)
Page 1
1 System Combination
1.1. System Breakdown
Note :
The table below show the breakdown for speaker combinations used in main unit systems.
SB-PT550G-S consists of SB-HF550G-S (x2), SB-HS550G-S (x2),
SB-HC550G-S (x1).
System SC-PT550GT-S
Music center SA-PT550GT-S
Front speaker
SB-HF550G-S
Surround speaker SB-HS550G-S
Center speaker SB-HC550G-S
Subwoofer SB-HW550G-S
2
SB-HC550G
Page 2
2 Notes
This Service Manual does not contain the following information because of the similar construction between this model & base
model SB-HC550E-S/K:
- Assembling and Disassembling
- Connection of the speaker cables
- Connection of the wiring diagram
Please refer to the original Service Manual of SB-HC550E-S/K. (Order No. MD0703047CE)
Main differences between SB-HC550G-S and SB-HC550E-S/K.
- Specification
- Specification label
- Packaging condition
2.1. Packaging Information (SB-HC550G-S)
Note :
Please refer to service manua l of SB-HF550G-S (MD0706035AE), for more information on the packaging condition for SB-
HC550G-S.
3
SB-HC550G
