PSG1403011CE

Service Manual

CD Stereo System

Model No. SA-AKX58PH
SA-AKX58PN
SA-AKX58GN
SA-AKX78PH
SA-AKX78PN

Product Color: (K)...Black Type

The illustration shows SC-AKX78.
Remote
Control
SB-AKX78 SB-AKW78 SB-AKX78

messes

Ififimm

Please refer to the original service manual for:

0 CD Mechanism Unit, Order No. PSG1303059AE

0 Speaker system SB-AKX78PN-K, Order No. PSG1403012CE

0 Speaker system SB-AKW78PN-K, Order No. PSG1403012CE (For AKX78)

A WARNING

This service information is designed for experienced repair technicians only and is not designed for use by the general public,

It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians Any attempt to service
or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.

IMPORTANT SAFETY NOTICE
There are special components used in this equipment which are important for safety. These parts are marked by A in the Schematic
Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced
with manufacturers specified parts to prevent shock, fire or other hazards Do not modify the original design without permission of

manufacturer.

TABLE OF CONTENTS

PAGE

1 Safety Precautions ----------------------------------------------- 3
1.1. General Guidelines -------
1.2. Before Use (For PH only)-
1.3. Before Repair and Adjustment
1.4. Protection Circuitry ------------
1.5. Power Supply using SMPS -
1.6. Safety Parts Information

2 Warning -----------------------------
2.1. Prevention of Electrostatic Discharge (ESD)

to Electrostatically Sensitive (ES) Devices ---------- 8
2.2. Precaution of Laser Diode ------------------------------- 8
2.3. General description about Lead Free Solder

(PbF) --------------------------------------------

2.4. Handling Precautions for Traverse Unit

Panasonica

PAGE
breakdown

electrostatic

2.5. Grounding for
prevention ------

3 Service Navigation -
3.1. Service Information

4 Specifications --------------

5 Location of Controls and Components--
5.1. Remote Control Key Button Operation
5.2. Main Unit Key Button Operation ---------

6 Service Mode--

6.1. Cold-Start -

6.2. Sales Demonstration Lock Function
6.3. Service Mode Table ---------------------
6.4. Doctor Mode Table ------
6.5. Self-Diagnostic Mode --

© Panasonic Corporation 2014. All rights reserved.
