Page 2

SA-AK570PL l SA-AK570GCP

Wow and flutter 0.18 % (WRMS)
Fast forward and rewind time
Approx. 120 seconds with C-GO cassette tape
l DISC SECTION
Disc played [8 cm or 12 cm]
(1) CD-Audio (CD-DA)
(2) CD-R/RW (CD-DA, MP3 formatted disc)
(3) MP3
' MPEG-1 Layer 3, MPEG-2 Layer 3
Pick up
780 nm

Semiconductor laser

Wavelength

Beam Source
Audio output (Disc)
Number of channel 2 (FL, FR)
FL = Front left channel
FR = Front right channel
I USE SECTION

USB Port

USB Standard

Media file format support

USB 2.0 full speed

MP3 (.mpa)
Bit rate 128 kbps / 192 kbps / 320 kbps
USB recording speed 1x, max 4x (CD only)
I GENERAL

Power supply
AC 120 v, 60Hz (PL only)
AC 110 to 127/220 to 240 V, 50/60 HZ (GCP only)
141 w (PL Only)
124 w (GCP Only)
250x331x334 mm
4.9 kg
0 to 40°C
35 to 80% RH (no condensation)
Power consumption in standby mode:

Power consumption

Dimensions (WxHxD)

Mass

Operating temperature range
Operating humidity range

0.3 W (approx) (PL only)
0.5 W (approx) (GCP only)

I SYSTEM
SC-AK570 (PL) Music center: SA»AK570 (PL)
Speaker: SB-AK570 (PL)

SC-AK570 (GCP) Music center: SA-AK57O (GCP)

MP3 ('.mp3) Speaker: SB-AK570 (PL)
USB device file system For information on speaker system, please refer to the original
FAT 12 Service Manual (Order No. MD0805011CE) for SB-AK570PL-K.
FAT 16 Notes:
FAT 32 1.3pecitications are subject to change without notice. Mass and
USB p0 power 500 mA (Max) dimenSIons are approkimate. . '
USB Ripping (recording) 2.Tota| harmonic distortion is measured by the digital spectrum
analyzer.
Recording file format
A WARNING

This service information is designed for experienced repair technicians only and is not designed tor use by the general public.

It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product,
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service
or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.

CONTENTS

1 Safety Precautions -------

2 Prevention of Electro Static Discharge (ESD) to
Electrostatically Sensitive (ES) Devices -------------------------------- 5

3 Handling Precautions for Traverse Unit

4 Precaution 01 Laser Diode-
5 About Lead Free Solder (PbF)
6 Operation Procedures --------------------------------------------------------- 10

7 Self diagnosis and special mode setting ............................. 14
----- 22
9 Disassembly and Assembly of Traverse Unit Assembly in

8 Assembling and Disassembling ..............

Play Position ................

10 Service Fixture and Tools
11 Service Positions ................................................................ 53

Page

12 Procedure tor checking Operation of Individual Parts of Deck
..................................................... 55
13 Measurement And Adiustments ........................................... 55

Mechanism Unit .....

14 Voltage Measurement and Waveform Chart
15 Wiring Connection Diagram

16 Block Diagram ................

17 Notes 0t Schematic Diagram .............................................. 55
18 Schematic Diagram ............................................................. 57
19 Printed Circuit Board ...................................................... 105
20 IIIUStration of ICs, Transistors and Diodes ........................ 113

21 Terminal Function of Integrated circuits 114
22 Exploded Views .................................. 11-,
23 Replacement Parts List ..................................................... 121
