ORDER NO. MD0705011AE

rvice Manual

DVD Home Theater Sound System

SA-PT150EE
Colour
(8). .Silver Type

Remote
se.w34o (Silver) -
SB-HW150 (Black) SB'HS1 5 SB'HS1 51 friggiiiler'

SB-HC150

l~l

1-

SB-HF150 SA

Notes: This model is based on SA-PT150EEBEG-S. Please refer to the original service manual (Order no.
MD0703044CE).

Specifications
[GENERAL At 1 kHz and total harmonic of 10%
Power Supply: AC 230 V, 50Hz [Front Ch: 55 W / Channel (5 (2)
Power Consumption: 105 W [Center Ch: 55 W / Channel (5 (2)
Power Consumption in Standby Mode: [Surround Ch: 55 W / Channel (5 (2)
approx. 1 W At 100 Hz and total harmonic of 10%
Dimensions (WXHXD): 4BOXBOX342 mm [Subwoofer Ch: 55 W / Channel (5 (2)
Mass: Main unit approx. 3 kg DlN Output Power: Dolby Digital Mode:
Operating Temperature Range: +5°C to +35°C (+41°F to [Total DIN Dolby Digital mode power:
+95°F) 150 w
Operating Humidity Range: 5% to 90% RH (no At 1 kHz and total harmonic of 1%
condensam") [Front Ch: 25 w / Channel (5 o)
IAMPLIFIER SECTION [Center Ch: 25 W / Channel (5 Q)
RMS Output Power: Dolby Digital Mode [Surround Ch: 25 W / Channel (5 Q)
[Total RMS Dolby Digital mode power: At 100 Hz and total harmonic of 1%
330 W [Subwoofer Ch: 150 W / Channel (5 Q)

© 2007 Malsushita Electric Industrial 00., Ltd. All

I ®
rights reserved. Unauthorized copying and
distribution is a violation of law.
