Page 1
Important Safeguards and Precautions
2
INSTALLATION
1 POWER SOURCE CAUTIONOperate only from power source indicated on unit
or in this manual. If uncertain, have your Electric
Utility Service Company or Video Products Dealer
verify your home power source.
2 POWER CORD PLUGFor safety, this unit has a polarized type plug (one wide
blade), or a three-wire grounding type plug. Always
hold the plug firmly and make sure your hands are
dry when plugging in or unplugging the AC power cord.
Regularly remove dust, dirt, etc. on the plug.
POLARIZED PLUG CA UTION: The plug fits into outlet only one way. If it cannot be
fully inserted, try reversing it. If it still will not fit, have
an electrician install the proper wall outlet. Do not
tamper with the plug.
GR OUNDING PLUG CA UTION: The plug requires a three-hole grounding outlet.
If necessary, have an electrician install the proper
outlet. Do not tamper with the plug.
3 POWER CORDTo avoid unit malfunction, and to protect against
electrical shock, fire or personal injury:
- Keep power cord away from heating appliances
and walking traffic. Do not rest heavy objects on,
or roll such objects over the power cord.
- Do not tamper with the cord in any way.
- An extension cord should have the same type
plug (polarized or grounding) and must be securely
connected.
- Overloaded wall outlets or extension cords are
fire hazards.
- Frayed cords, damaged plugs, and damaged or
cracked wire insulation are hazardous and should
be replaced by a qualified electrician.
4 DO NOT BLOCK VENTILATION HOLESVentilation openings in the cabinet release heat
generated during operation. If blocked, heat
build-up may result in a fire hazard or heat
damage to discs.
For your protection:
a. Never cover ventilation slots while unit is ON,
or operate unit while placed on a bed, sofa,
rug, or other soft surface.
b. Avoid built-in installation, such as a book case
or rack, unless properly ventilated.
5 AVOID EXTREMELY HOT LOCATIONS OR
SUDDEN TEMPERATURE CHANGES
Do not place unit over or near a heater or radiator, in
direct sunlight, inside closed vehicles,
in high temperature [over 95 °F (35 °C)], or in over
75% humidity. If unit is suddenly moved from a
cold place to a warm one, moisture may condense in
unit and on the tape causing damage. Never subject
unit to vibration, impact, or place it so that the
surface is tilted as internal parts may be seriously
damaged.
6 TO AVOID PERSONAL INJURYNever place unit on support or stand that is not
firm, level, and adequately strong. The unit could
fall causing serious injury to a child
or adult and damage to the unit.
Move any appliance and cart
combination with care.
Quick stops, excessive force, and
uneven surfaces may cause objects to overturn.
Carefully follow all operating instructions.
USING THE UNIT Before unit is brought out of storage or moved to a new location,
refer again to the INSTALLATION section of these safeguards.
1 KEEP UNIT WELL AWAY FROM WATER OR
MOISTURE, such as vases, sinks, tubs, etc. 2 IF EXPOSED TO RAIN, MOISTURE, OR
STRONG IMPACT, unplug unit and have it inspected by
a qualified service technician before use.
3 ELECTRICAL STORMSDuring a lightning storm, or before leaving unit unused for
extended periods of time, disconnect all equipment from the
power source as well as the antenna and cable system.
4 WHEN UNIT IS PLUGGED IN DO NOT OPERATE IF:
- liquid has spilled into unit.
- unit was dropped or otherwise damaged.
- unit emits smoke, odours, or noises.
Immediately unplug unit, and have it inspected by a service
technician to avoid potential fire and shock hazards.
Never drop or push any object through openings in unit.
Touching internal parts may cause electric shock or fire hazard.
Do not put any foreign object on the tray.
Keep magnetic objects, such as speakers, away from
unit to avoid electrical interference.
5 USING ACCESSORIESUse only accessories recommended by the manufacturer to
avoid risk of fire, shock, or other hazards.
6 CLEANING UNITUnplug unit. Use a clean, dry, chemically untreated cloth to
gently remove dust or debris. DO NOT USE cleaning fluids,
aerosols, or forced air that could over-spray, or seep into unit and
cause electrical shock. Any substance, such as wax, adhesive
tape, etc. may mar the cabinet surface. Exposure to greasy,
humid, or dusty areas may adversely affect internal parts.
READ AND RETAIN ALL SAFETY AND
OPERATING INSTRUCTIONS. HEED ALL
WARNINGS IN THE MANUAL AND ON UNIT
SERVICE 1 DO NOT SERVICE PRODUCT YOURSELFIf, after carefully following detailed operating instructions, the
unit does not operate properly, do not attempt to open or remove
covers, or make any adjustments not described in the manual.
Unplug unit and contact a qualified service technician.
2 REPLACEMENT OF PARTSMake sure the service technician uses only parts specified
by the manufacturer, or have equal safety characteristics
as original parts. The use of unauthorized substitutes may
result in fire, electric shock, or other hazards.
3 SAFETY CHECK AFTER SERVICINGAfter unit is serviced or repaired, request that a thorough safety
check be done as described in the manufacturers service
literature to ensure video unit is in safe operating condition.
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENTANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC- NATIONAL ELECTRICAL CODE
OUTDOOR ANTENNA INSTALLATION 1 SAFE ANTENNA AND CABLE CONNECTIONAn outside antenna or cable system must be properly
grounded to provide some protection
against built up static charges
and voltage. Section 810
of the National Electrical Code,
ANSI/NFPA 70 (in Canada,
part 1 of the Canadian Electrical
Code) provides information
regarding proper grounding of
the mast and supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding conductors,
location of antenna discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
2 KEEP ANTENNA CLEAR OF HIGH VOLTAGE
POWER LINES OR CIRCUITS
Locate an outside antenna system well away from power
lines and electric light or power circuits so it will never touch
these power sources should it ever fall. When installing
antenna, absolutely never touch power lines, circuits or
other power sources as this could be fatal.
For assistance, please call : 1-800-211-PANA(7262) or send e-mail : consumerproducts@panasonic.com
DM2092 (P02-3).p652002/06/19, 14:51 2
Page 2
3
CAUTION:UNIT IS A CLASS I LASER PRODUCT.
HOWEVER THIS UNIT USES A VISIBLE LASER BEAM WHICH COULD
CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE
SURE TO OPERATE THE UNIT CORRECTLY AS INSTRUCTED.
WHEN THIS UNIT IS PLUGGED TO THE WALL OUTLET, DO NOT
PLACE YOUR EYES CLOSE TO THE OPENING OF THE DISC TRAY
AND OTHER OPENINGS TO LOOK INTO THE INSIDE OF THIS UNIT.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT ATTEMPT TO REPAIR THE
UNIT YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL. CAUTION:LASER RADIATION
WHEN OPEN. DO NOT
STARE INTO BEAM.
This symbol warns the user that uninsulated voltage within the unit
may have sufficient magnitude to cause electric shock. Therefore, it is
dangerous to make any kind of contact with any inside part of this unit.
This symbol alerts the user that important literature concerning the
operation and maintenance of this unit has been included. Therefore,
it should be read carefully in order to avoid any problems.
CAUTION: TO REDUCE THE RISK
OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS
INSIDE REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL
RISK OF ELECTRIC SHOCK
DO NOT OPENCAUTION
Region Management Information
Region Management Information: This unit is designed and
manufactured to respond to the Region Management Information
that is recorded on a DVD disc. If the Region number described
on the DVD disc does not correspond to the Region number of
this unit, this unit cannot play this disc. The Region number
for this unit is 1. 1
This product utilizes both a Cathode Ray Tube (CRT) and other components that contain lead.
Disposal of these materials may be regulated in your community due to environmental
considerations. For disposal or recycling information please contact your local authorities, or the
Electronics Industries Alliance:
Safety Precautions/Mesures de sécurité
Warnin g : To prevent fire or shock hazard, do not expose this equipment to rain or moisture.
Caution : To prevent electric shock, match wide blade of plug to wide slot, fully insert.
Avertissement : Afin de prévenir tout risque dincendie ou de chocs électriques, ne pas
exposer cet appareil à la pluie ou à une humidité excessive.
Attention : Pour éviter les chocs électriques, introduire la lame la plus large de la fiche
dans la borne correspondante de la prise et pousser jusquau fond.
FCC WARNING :Any unauthorized changes or modifications to this equipment
would void the users authority to operate.
ATTENTION:RAYONNEMENT LASER
EN CAS DOUVERTURE.
NE PAS REGARDER
DANS LE FAISCEAU.
(Inside of product)
FCC NOTICE:
This equipment has been tested and found to comply with part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when operated in a residential
environment. If this eqiupment does cause interference to radio or television reception, which can be
determined by turning the equipment off and on, use the equipment in another location and/or utilize an
electrical outlet different from that used by the receiver. If necessar y, consult the dealer or an
experienced radio/TV technician for help. You may find the booklet, 'Something About Interference'
available from FCC local regional offices helpful.
This television receiver provides display of television closed captioning.
