Page 1
2
VQT0R73
Getting started
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the
user to the presence of uninsulated dangerous
voltage within the products enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
-If you see this symbol-
(Inside of product)
Warning and Important Information
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR PRODUCT DAMAGE, DO NOT
EXPOSE THIS APPARATUS TO RAIN,
MOISTURE, DRIPPING OR SPLASHING AND
THAT NO OBJECTS FILLED WITH LIQUIDS,
SUCH AS VASES, SHALL BE PLACED ON THE
APPARATUS.
CAUTION!
DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE,
BUILT-IN CABINET OR IN ANOTHER CONFINED SPACE.
ENSURE THE UNIT IS WELL VENTILATED. TO PREVENT
RISK OF ELECTRIC SHOCK OR FIRE HAZARD DUE TO
OVERHEATING, ENSURE THAT CURTAINS AND ANY OTHER
MATERIALS DO NOT OBSTRUCT THE VENTILATION VENTS.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE SCREWS.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
Information on Disposal in other Countries outside the
European Union
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your
local authorities or dealer and ask for the correct
method of disposal.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
THE FOLLOWING APPLIES ONLY IN THE U.S.A.
Note to CATV system installer:
This reminder is provided to call the CATV system installers
attention to Article 820-40 of the NEC that provides guidelines for
proper grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system of the
building, as close to the point of cable entry as practical.
The socket outlet shall be installed near the equipment and easily
accessible or the mains plug or an appliance coupler shall remain
readily operable.
THE FOLLOWING APPLIES ONLY IN THE U.S.A.
FCC Note:
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
-‰¥Reorient or relocate the receiving antenna.
-‰¥Increase the separation between the equipment and receiver.
-‰¥Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-‰¥Consult the dealer or an experienced radio/TV technician for
help.
FCC Caution: To assure continued compliance, follow the
attached installation instructions and use only shielded interface
cables when connecting to peripheral devices.
Any changes or modifications not expressly approved by the
party responsible for compliance could void the users authority to
operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Responsible Party:
Panasonic Corporation of North America
One Panasonic Way
Secaucus, NJ 07094
Telephone No.: 1-800-211-7262
RQLS0233
VARNING SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA DEL
ÄR ÖPPNAD. BETRAKTA EJ STRÅLEN.
VORSICHT SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG, WENN ABDECKUNGGEÖFFNET. NICHT DEM STRAHL AUSSETZEN.
ATTENTION RAYONNEMENT LASER VISIBLE ET INVISIBLE EN CAS DOUVERTURE.EXPOSITION DANGEREUSE AU FAISCEAU.
DANGER VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID DIRECT EXPOSURE TO BEAM. (FDA 21 CFR) CAUTION VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM. (IEC60825-1)
ADVARSEL SYNLIG OG USYNLIG LASERSTR ÅLING VED ÅBNING. UNDG Å UDSÆTTELSE FOR STRÅLING. VARO! AVATTAESSA OLET ALTTIINA N ÄKYVÄÄ JA NÄKYMÄTÖN
LASERSÄTEILYLLE. ÄLÄ KATSO SÄTEESEEN.
ADVARSEL SYNLIG OG USYNLIG LASERSTR Ã…LING NÃ…R DEKSEL Ã…PNES. UNNG Ã… EKSPONERING FOR STRÃ…LEN.
ES40VP&PC.book 2 ページ ï¼’ï¼ï¼ï¼•å¹´ï¼™æœˆï¼–æ—¥ã-ç«æ›œæ—¥ã-åˆå‰ï¼‘ï¼æ™‚23分
Page 2
Getting started
3
VQT0R73
Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the applicable safety
instructions listed below. Keep these operating instructions handy for future reference.
(1) Read these instructions.
(2) Keep these instructions.
(3) Heed all warnings.
(4) Follow all instructions.
(5) Do not use this apparatus near water.
(6) Clean only with dry cloth.
(7) Do not block any ventilation openings. Install in accordance with
the manufacturers instructions.
(8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
(9) Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding-type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.(10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
(11) Only use attachments/accessories specified by the
manufacturer.
(12) Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
(13) Unplug this apparatus during lightning storms or
when unused for long periods of time.
(14) Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
-ˆ«Cautions as to condensation
Condensation can cause unreliable playback of VHS recordings.
Condensation may form in the following cases,
-‰¥The unit is brought from cold surroundings into a well-heated room.
-‰¥The unit is suddenly brought from cool surroundings, such as an
air-conditioned room or car, to a place which is hot and humid.
-‰¥During the rainy season.
In any of the above-mentioned conditions, do not operate the unit for
at least 2 hours. The unit is not equipped with a dew sensor.
-ˆ«Other precautions for installation
-‰¥The unit should not be installed or operated near large magnets or
electromagnetic devices. Such devices can damage pre-recorded
VHS recordings.
-‰¥Do not place any heavy objects atop the unit, and do not install it in
a confined space. Please allow for adequate air circulation.
-‰¥The unit should not be mounted in a vertical position. Its designed
to operate in the horizontal position.
-‰¥Pages to be referred to are indicated as (l ±±).
-‰¥The explanations concerning discs are indicated by [DVD], and
those concerning video are indicated by [VHS].
-‰¥These operating instructions describe operations mainly using the
remote control.
-‰¥The contents of the screens used in these instructions may not
necessarily match what you will see on your screen.
-‰¥The displays shown in these instructions are examples. Actual
display depends on discs.You can enjoy both DVD and VHS with the unit.
This DVD Recorder can record images and sounds in high quality to
rapid random access capable DVD media. This has resulted in many
new features that outperform older tape formats. The following
information summarizes a few of these features.
ªDVD
Progressive output (l14, 19)
If you connect the unit with a progressive output compatible TV, you
can enjoy higher-quality and less flickering images than conventional
TVs (of the interlace output type) can present.
Finalize (l31)
This function enables you to play recorded DVD-R, DVD-RW (DVD-
Video format) and +R on other players.
Instant play (l33)
This function can quickly find and play a video program you wish to
watch. Direct Navigator guides you to the beginning of a previously
recorded video program immediately.
Quick view (l20)
This function allows you to watch news, information and other
programs in a short time.
Chasing play (l26)
There is no need to wait until recording is complete. Without stopping
recording, you can play the video program currently being recorded
from its beginning.
Instant recording (l24)
You no longer need to search for empty disc space. By pressing the
recording button, the unit finds available recording space and begins
recording right away.
Simultaneous recording and play (l26)
With this function, you can play a previously recorded video program
while recording another program.
Time slip (l21, 26)
This function enables you to jump to the scene you specify during
play and also while recording.
One touch transfer (dub) (l55, 56)
This function can copy video from VHS to DVD and vice versa.
ªVHS
Long recording (l49)
With this function, you can record approx. 10 hours of video onto a
T-120 cassette, for example.
IMPORTANT SAFETY INSTRUCTIONS
Precautions for installation
Do not place the unit on
amplifiers or equipment
that may become hot.
The heat can damage the unit.
Before moving the unit, ensure the disc tray is empty.
Failure to do so will risk severely damaging the disc and the
unit.
About descriptions in these operating
instructions
Useful features
Getting started
