ORDER NO. ACED9504093

Service Manual

AUTOMOTIVE CONSUMER ELECTRONICS

CQ-RZBOLEE
CQ- R24OLEE

; Removable Face High-Power Cassette / Receiver

i
i

< CQ-R240LEE >

g Bothy noise reduction «manufactured under license from Dolby Laboratories Licensing Corporation
' DO LBY" and the double- D symbol DC) are trad: marks of Dolby Laboratories Licensing Corporation,

I FEATURES

0 PLL (Phase Locked Loop) synthesizer tuning.

o 20-Stations Preset (5-FM1, 5-FM2, 5-FM3, 5-AM).

0 Metal (Cr02)/Normal Tape Selector.

0 Electronic Control of Volume, Bass, Treble, Balance and Fader.
O Loudness function (CQ-R230LEE only).

0 H.D.B (High Definition Bass) function (CQ-R240LEE only).

0 Dolby NR function (CQ-R24OLEE only)

0 Detachable Face Plate Security

A WARNING
This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a
product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians Any attempt to
service or repair the product or products dealt with in this service information by anyone else could result in serious injury or
death.

©1935 Malsushita Communication industrial 00., Ltd.
All rights reserved. Unauthorized copying and

. I
Panasonic
