Page 1
En-2
Features
TX-RZ900/TX-RZ800:
ï½¥ Equipped with 7 ch amplifier
ï½¥ Supports playback in Do by Atmos format and has Dolby
Surround listening mode
ï½¥ Supports playback in DTS:X format and has DTS
Neural:X listening mode
ï½¥ THX Select2 Plus certified
ï½¥ Equipped with 4K compat ble HDMI IN/OUT jacks
ï½¥ Equipped with 2 HDMI output jacks
ï½¥ Supports the HDMI Standby Through function which
allows transmission from players to the TV in standby
state
ï½¥ Supports HDCP2.2 (supported by HDMI IN1 to IN5/
HDMI OUT MAIN/SUB)
ï½¥ Supports ARC (Audio Return Channel)
ï½¥ Supports variety of network functions such as Internet
Radio, DLNA, AirPlay, etc.
ï½¥ Supports Wi-Fi and BLUETOOTH
®
ï½¥ Bi-Amping capability
ï½¥ A/V Sync Function to correct deviation of audio and
video
ï½¥ Multi-zone function (Zone 2 and Zone 3) which allows
you to play something in the main room while enjoying
a different source in a separate room (Video and audio
can also be output to Zone 2 through HDMI)
ï½¥ Music Optimizer-„¢ for compressed digital music files
ï½¥ Phase Matching Bass System
ï½¥ Automatic speaker setup available using supplied
calibrated microphone (AccuEQ Room Cal bration)
ï½¥ Supports playback of MP3, WMA, WMA Lossless,
FLAC, WAV, Ogg Vorbis, Apple Lossless, DSD, Dolby
TrueHD via network and USB storage device (the
supported formats will differ depending on the use
environment)
TX-RZ900:
ï½¥ The two front channels have parallel push-pull circuits
for reproducing powerful bass
ï½¥ Equipped with a high-class toroidal transformer as an
independent power source for the audio circuitry
Page 2
En-3
1 249 6 578
ON S T
QR
P
3 GH
IJLM
K U VW X
F
(European, Australian
and Asian models)
Front Panel
1 zON/STANDBY button
: Turns the unit on or into
standby mode.
2 PURE AUDIO button and indicator : The display and
analog video circuits are turned off to switch the unit to
PURE AUDIO mode and provide purer sound.
3 HYBRID STANDBY indicator : Lights if the unit enters
standby mode when the HDMI Standby Through,
USB Power Out at Standby, Network Standby or
BLUETOOTH Wakeup function is enabled.
4 DTS:X indicator : Lights when playing DTS:X. 5 DOLBY ATMOS indicator: Lights when playing Dolby
Atmos.
6 Display 7 Remote control sensor: Receives signals from the
remote controller.
8 Input selector buttons : Switches the input to be
played. Each button is assigned to the following jacks.
Button Jack Button Jack
BD BD/DVD G2 GAME 2
CBL CBL/SAT AUX AUX
STM STRM BOX CD CD
PC PC PHN PHONO
G1 GAME 1 TV TV
ï½¥ Use the TUN button for AM/FM radio, the NET button
for network features such as Internet radio and
USB playback, and the
button for BLUETOOTH
features.
ï½¥ The assigned jacks can be changed. For how to
make settings, see "1. Input/Output Assign" in
"Advanced Settings (Setup Menu)" in the Advanced
Manual.
9 ZONE2/3 button : Controls the multi-zone function. F MASTER VOLUME: Allows you to adjust the volume.
G LISTENING MODE button/dial : Allows you to select
the listening mode. Press the button repeatedly to select
a category from "MOVIE/TV", "MUSIC", "GAME", then
turn the dial to change the mode.
H TONE button/dial : Adjusts the high tone and low tone.
Press the button repeatedly to select the item to adjust
from "Bass", "Treble" and "Phase Matching Bass", and
turn the dial to adjust.
I Front flap
J SLEEP button : Allows you to specify a time period after
which the unit enters standby automatically.
K PHONES jack: Stereo headphones with a standard plug
are connected.
