Onkyo DVSP 302 Service Manual

Page 1

DV-SP302

Ref. No. 3814

ONKYO SERVICE MANUAL 2"

DVD PLAYER
MODEL DV-SP302

8%;

CD
6)
Q9

K

(I

OEOOO

Black, Silver and Golden models RC'S7SDV
CDD 120V AC, 60Hz
CUA CUT) 100-240V AC, 50/60Hz
CUK, CUR

SAFETY-RELATED COMPONENT
WA R N I N G ! !

THE MARK A FOUND ON SOME COMPONENT
PARTS INDICATES THE CRITICAL FOR RISK OF
FIRE AND ELECTRIC SHOCK.

WHEN REPLACING, BE SURE TO USE PARTS OF
IDENTICAL DESIGNATION.

MAKE LEAKAGE-CURRENT 0R RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE To THE CUSTOMER.

ONKYO®

IMAGINATIVE SIGHT & SOUND
