CP-1037F

SERIAL NO. 3215

ONKYO SERVICE MANUAL

FULLY AUTOMATIC TURNTABLE

MODEL CP-1037F

SAFETY-RELATED COMPONENT WARNINGII

COMPONENTS IDENTIFIED BY MARK ON
THE SCHEMATIC DIAGRAM AND IN THE PARTS
LIST ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE THESE COM-
PONENTS WITH ONKYO PARTS WHOSE PARTS
NUMBERS APPEAR AS SHOWN IN THIS MANUAL.

MAKE LEAKAGECURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT
EXPOSED PARTS ARE ACCEPTABLY IN-
SULATED FROM THE SUPPLY CIRCUIT BEFORE
RETURNING THE APPLIANCE TO THE

CUSTOMER.

SPECIFICATIONS

Type: 2-speed fully automatic
turntable

Turntable Platter: 30 cm (12) aluminum
diecast

Motor: Electronic servo DC motori
belt drive

Speeds: 33-1/3 rpm, 45 rpm

Wow & Flutter: 0.05% (WRMS)

Signal-to-Noise Ratio: 67 dB (DIN B)

Tonearm: Lightweight straight-line

static balanced pipe toneann

with detachable headshell
(ADC type connector) and
counterweight with direct
tracking force read out.

Suitable Cartridge Weight:
Adjustable Range:
Maximum Length:
Effective Arm Length:
Overhang:

Maximum Tracking Error:

Cartridge:
Type:

Frequency Response:
Recommended Load
Impedance:
Recommended Trackig
Force:
Output Voltage:
Replacement Stylus:
Power Supply:
DimensioanX H X D):

Weight:

5~9 grams

3 grams

270 mm

213 mm

14 mm

+3 degrees, -l.0 degrees
(offset angle 21 degrees)

Induced magnet
00661
20 Hz 7 20,000 Hz

47 kohms

2 grams

2.5mV

DN66ST

AC 120V, 60 Hz
418mmX372mmX 130mm
[6-1/2" X 144/2 X 5-1/2
3.5 kg (77 lbsi)

Optional Recommended Headshell: SH-21E

Due to further product improvements, specifications are
subject to change without onticei
