For 20 years, THX ® has made our A/V receivers disappear. Its no easy trick. Reproducing the high fi delity and volume levels of
commercial movie theater-the kind of sound that pulls you from your seat and into the action-calls for an A/V receiver engineered
to the highest standards. It demands a robust power supply, bulletproof construction, and amplifi ers that stay composed as the volume
climbs above reference level. To wear a THX badge, the A/V receiver must pass more than 2,000 laborator y tests analyzing ever y aspect
of audio performance. Onkyo A/V receivers not only guarantee THX cinema reference sound right out of the box, they eliminate other
distractions that can bring you out of the movie. Ever ything from initial setup to ever yday operation is more intuitive, reducing the
time it takes to load content and allowing you to make in-program adjustments without disruption. So when the lights go down, theres
nothing standing between you and a spellbinding cinema experience thats reproduced exactly as the fi lmmaker intended.
Two Decades of Superior Sound
2 THX and the THX logo are registered trademarks of THX Ltd. The Tex character is ©1996 THX Ltd. All rights reser ved.
Page 2
Wi-Fi RouterA/V
Receiver
PC
NAS
Wi-Fi for Network Audio Streaming
Stream a wide range of high-resolution, lossless, and compressed audio fi les from
smar tphone, PC, and media ser ver to your Wi-Fi-cer tifi ed Onkyo network A/V
receiver-no cables or adapters required. Our free remote app lets you browse,
select, and stream online media sources (such as Spotify or TuneIn Radio) as well
as the music stored on your smar tphone, NAS, or PC with no
loss in quality. You can also enable AirPlay by connecting our
optional DS-A5 RI dock.
New for 20 13
Bluetooth Technology Inside
Enjoy the music stored on any Bluetooth-compatible device instantly
-just pair up, choose a track, and hit play. The Bluetooth wireless streaming
technology on board selected Onkyo network A/V
receivers makes casual listening easy.
New for 2013
Built-in
Wireless Audio
Streaming
Wi-Fi
Bluetooth
Remote Apps for iPhone and Android(See page 4 for more information)
Digital-to-Analog Conversion StageOur fl agship model employs 192 kHz/32-bit Burr-Brown DACs to achieve the best dynamic
performance and better tolerance to clock jitter. All other models are graced with
high-performance Burr-Brown 192 kHz/24-bit DACs.
VLSC -„¢ (Vector Linear Shaping Circuitry) In addition to quality DACs, VLSC employs a unique digital-to-analog conversion circuit to
fur ther mitigate the effects of signal noise. Our technology produces a
pristine analog signal based on the digital source.
More Features, Better Sound
3
Whole-House Audio DistributionUse the powered outputs on selected Onkyo A/V receivers to drive audio in up to three zones
at once. Line outputs turn the receiver into a sophisticated
pre-amp and network media streamer when connected to an
existing hi-fi .
Connect Your Smartphone with MHL -„¢
The designated HDMI/MHL charging por t on selected network A/V receivers lets you watch
HD video stored on smar tphone, tablet, and other compatible devices
with up to 7.1 channels of surround sound.
WRAT (Wide Range Amp Technology)WRAT incorporates a low-negative-feedback circuit
design to extract full-spectrum dynamics from any
recording, resulting in a distinctively musical sound.
Closed ground-loop circuits and discrete output
transistors tame distor tion, while High Instantaneous
Current Capability draws on a deep reser voir of
power to effor tlessly handle
large dynamic gains.
Three-Stage Inverted Darlington CircuitryThree-Stage Inver ted Darlington Circuitr y is a key
enhancement to WRAT. Based on proven Darlington
circuit topology, the exclusive inver ted design is suited
to high-energy applications where ver y low distor tion
is required.
Hassle-Free Video SwitchingInstaPrevue -„¢ technology makes switching between gaming consoles, Blu-ray
Disc player, and cable TV much easier, naming the source devices connected via
HDMI and offering thumbnail previews of available content.
Phase-Matching Bass BoostPM Bass works to control the phase timing of different frequencies to preser ve the natural
clarity of the mid-range-allowing room for vocals and strings to
breathe-while ensuring a powerful bass response at all volumes.
Hybrid Standby Saves PowerHybrid Standby mode maintains HDMI and network connectivity while
the receiver is powered down. This means you can watch TV and use your
media players on occasions when you dont require surround sound.
Four Thrilling Audio Modes for Gamers Experience stunning realism and impact with four gaming modes-Rock, Spor ts, Action, or Role
Playing Game (RPG)-optimizing the surround sound to help you get the most from your
favorite games.
Overlaid OSD for Stress-Free Operation At the touch of a button, easy-to-navigate menus appear overlaid
on screen. The HDMI-enabled OSD gives instant access to the most
useful home cinema settings, including speaker levels and listening
mode selection, making in-program adjustments quick and easy.
Optimized for 4K Ultra HDThe latest Onkyo network A/V receivers can pass 4K Ultra HD video from media player
through to a compatible display or projector via HDMI ®. Selected models also feature Qdeo -„¢
upscaling technology for fl awless 1080p or 4K video playback of lower-
resolution sources.
High-Resolution Audio DecodingExperience the latest in studio master-quality sound, with Dolby ® TrueHD and DTS-HD Master
Audio -„¢ decoding from Blu-ray Disc. Onkyo network A/V receivers also suppor t a variety
of hi-res music formats streamed from NAS and PC,
including 192 kHz/24-bit FLAC, DSD, and Dolby
® TrueHD.
Audyssey Equalization SolutionsThe Audyssey MultEQ ® XT32, MultEQ ®, and 2EQ ® room acoustic correction systems offered
on selected network A/V receivers are designed to equalize
the surround sound to suit the shape of your listening space.
More HDMI ® Inputs and Outputs Onkyo includes more HDMI inputs and outputs on its A/V receivers than most other brands,
accommodating extra devices as your system grows. The second HDMI output on selected
models offers 1080p content in Zone 2, while on other models it is
designed to connect both movie projector and TV.
Surround Sound Upmixing SolutionsSelected A/V receivers are bundled with class-leading audio upmixing technologies, including
DTS Neo:X -„¢, Audyssey DSX ®, and Dolby ® Pro Logic ® IIz. These take stereo or
5.1 soundtracks and mix them for playback
through seven, nine, or eleven channels.
New for 20 13
New for 2013
