2Thank you for purchasing ...Before usingMain Features·High-Quality Separate Component ·WRAT (Wide Range Amp Technology) Circuit ·Processor In/Out, Subwoofer Pre Out ·Six-audio Source Inputs Thank you for purchasing the ONKYO A-905TX Integrated Stereo Amplifier. Please read this manual thoroughly before making any connection or turning on the power. Follow these instructions to obtain optimum performance and maximum listening enjoyment from your new A-905TX. Please retain this manual for future reference. ·Acoustic Presence Circuit Naturally En- hances the Extreme Low Range ·Source Direct Function ·System Control Remote ControllerWARNING:TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.WARNINGRISK OF ELECTRIC SHOCK DO NOT OPENRISQUE DE CHOC ELECTRIQUE NE PAS OUVRIRAVISMemory Preservation This unit does not require memory preservation batteries. A built-in memory power back-up sys- tem preserves the contents of the memory dur- ing power failures and even when the unit is un- plugged. The unit must be plugged in order to charge the back-up system.The memory preservation period after the unit has been unplugged varies depending on climate and placement of the unit. On the average, memory contents are protected over a period of a few weeks after the last time the unit has been unplugged. This period is shorter when the unit is exposed to a highly humid climate.

Page 2

3 Before usingImportant Safeguards10.Power Sources ÐÊ The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance. 11.Polarization Ð If the appliance is provided with a polarized plug having one blade wider than the other, please read the following information:The polarization of the plug is a safety feature. The polarized plug will only fit the outlet one way. If the plug does not fit fully into the out- let, try reversing it. If there is still trouble, the user should seek the services of a qualified elec- trician. Under no circumstances should the user attempt to defeat the polarization of the plug. 12.Power-Cord Protection Ð Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, especially near plugs, convenience receptacles, and the point where they exit from the appliance. 13.Cleaning Ð The appliance should be cleaned only as recommended by the manufacturer. 14.Nonuse Periods Ð The power cord of the ap- pliance should be unplugged from the outlet when left unused for a long period of time. 15.Object and Liquid Entry Ð Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through openings. 16.Damage Requiring Service Ð The appliance should be serviced by qualified service per- sonnel when: A. The power-supply cord or the plug has been damaged; or B. Objects have fallen, or liquid has been spilled into the appliance; or C. The appliance has been exposed to rain; or D. The appliance does not appear to oper- ate normally or exhibits a marked change in performance; or E. The appliance has been dropped, or the enclosure damaged. 17.Servicing Ð The user should not attempt to ser- vice the appliance beyond that described in the operating instructions. All other servicing should be referred to qualified service personnel. 1.Read Instructions Ð All the safety and operating instructions should be read before the appliance is operated. 2.Retain Instructions Ð The safety and operating instructions should be retained for future reference. 3.Heed Warnings Ð All warnings on the appliance and in the operating instructions should be adhered to. 4.Follow Instructions Ð All operating and use instructions should be followed. 5.Water and Moisture Ð The appliance should not be used near water Ð for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, and the like. 6.Carts and Stands Ð The appliance should be used only with a cart or stand that is rec- ommended by the manufacturer. 6A. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven sur- faces may cause the appliance and cart combination to over- turn. 7.Wall or Ceiling Mounting Ð The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer. 8.Ventilation Ð The appliance should be situ- ated so that its location or position does not interfere with its proper ventilation. For ex- ample, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings; or if placed in a built-in installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings, there should be free space of at least 20 cm (8 in.) and an opening behind the appliance. 9.Heat Ð The appliance should be situated away from heat sources such as radiators, heat reg- isters, stoves, or other appliances (including amplifiers) that produce heat.PORTABLE CART WARNINGS3125A

Page 3

4PrecautionsDeclaration of ConformityWe, ONKYO EUROPE ELECTRONICS GmbH INDUSTRIESTRASSE 20 82110 GERMERING, GERMANY GERMERING, GERMANY ONKYO EUROPE ELECTRONICS GmbHA.HORIUCHIdeclare in own responsibility, that the ONKYO product describedin this instruction manual is in compliance with the corresponding technical standards such as EN60065, EN55013, EN55020 and EN61000-3-2, -3-3.1. Warranty Claim You can find the serial number on the rear panel of this unit. In case of warranty claim, please re- port this number. 2. Recording Copyright Recording of copyrighted material for other than personal use is illegal without permission of the copyright holder. 3. AC Fuse The fuse is located inside the chassis and is not user-serviceable. If power does not come on, con- tact your Onkyo authorized service station. 4. Care From time to time you should wipe the front and rear panels and the cabinet with a soft cloth. For heavier dirt, dampen a soft cloth in a weak solu- tion of mild detergent and water, wring it out dry, and wipe off the dirt. Following this, dry immedi- ately with a clean cloth. Do not use rough mate- rial, thinners, alcohol or other chemical solvents or cloths since these could damage the finish or remove the panel lettering. 5. Power WARNING BEFORE PLUGGING IN THE UNIT FOR THE FIRST TIME, READ THE FOLLOWING SECTION CARE- FULLY. The voltage of the available power supply differs according to country or region. Be sure that the power supply voltage of the area where this unit will be used meets the required voltage (e.g., AC 230 V, 50 Hz or AC 120 V, 60 Hz) written on the rear panel.For British model Replacement and mounting of an AC plug on the power supply cord of this unit should be performed only by qualified service personnel. IMPORTANT The wires in the mains lead are coloured in accor- dance with the following code: Blue : Neutral Brown : Live As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black. The wire which is coloured brown must be con- nected to the terminal which is marked with the letter L or coloured red. IMPORTANTA 5 ampere fuse is fitted in this plug. Should the fuse need to be replaced, please ensure that the replace- ment fuse has a rating of 5 amperes and that it is ap- proved by ASTA or BSI to BS1362. Check for the ASTA mark or the BSI mark on the body of the fuse.IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY. THERE IS A DAN- GER OF SEVERE ELECTRICAL SHOCK IF THE CUT OFF PLUG IS INSERTED INTO ANY 13 AMPERE SOCKET.If in any doubt, please consult a qualified electrician.For Canadian model For models having a power cord with a polarized plug:CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. Modele pour les Canadien Sur les modles dont la fiche est polarisŽe:ATTENTION: POUR ƒVITER LES CHOCS ƒLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQUÕAU FOND. Das private Onkyo Archiv © von Dirk Gardi
