KA3 Top Level Hardware Description
rev 0
PG 22 Jan 07

Introduction

The KA3 is a table-top DJ audio player with built in mixer, playing content from USB devices such
as flash drives and hard discs, as well as iPods. Effects are available that are useful to a DJ: pitch
shifting, scratching, looping and beatkeeping. A large LCD display is featured along with an
innovative user interface. The electronics are implemented in 3 main PCBs; the CPU board, the
Mixer board and the Control board.

This document describes the top level design of the system, and should be read in conjunction with
the circuit descriptions of the individual boards.

Block Diagram


Power in Record out

Ext audio A Main out
Ext audio B Headphone

Microphone

IPOD video

50 way cable

USB Serial
