DISASSEMBLY INSTRUCTIONS

(A)

(El

Bottom View

{C}
Fig. 1

Removing cabinet top and bottom cover. See Fig. 1.
1. Remove four cabinet screws (A) from left and right sides and lift off cabinet.
2. Remove three bottom cover screws (B) and lift off bottom cover.

Removing from panel. See Fig. 1.
1. Remove four screws (C) from top and bottom sides and lift off front panel,

Power Level indicator Alignment Method
1. Set 1 kHz, 8V on speaker output.
2. Meanwhiie, adjust VR601 and VRGOZ to 1.3Vdc on P601 of P2 and P4.
