CONTENTS
1. General . . . .
09/08/2012
www.nostatech.n|
2 RemovalProcedures ...... ................ .. ................ :3
2. 1. TopCover.... . .. . 3
2. 2. Bottom Cover . . ............................................. 3
2. 3. Front Panel Assy . . . . ........ . ..... 3
2. 4. Display 8: Control P.C.B. Assy . . . . . . 3
3. Parts Location for Electrical Adjustment ........ 4
4. Electrical Adjustments . . 4
4. 1. Power Ampli ier Section 4
4. 2. Tuner Section . 5
6. Mechanism Ass'y and Parts List . . . . 8
5. 1. Synthesis ............ 8
5. 2. Chassis Assy (A01) ......... . . . . . . . . . . . . 9
5. 3. Heat Sink Assy.(BOl) ................... . . .................. . ............ 10
5. 4. Front Chassis Assy (802) 10
6. Mounting Diagrams and Parts List . . . . . . 11
6. 1. AC Outlet P.C.B. Assy ......... . ........... 11
6. 2. Power Switch P.C.B. Assy ................. . . . 11
6. 3. Speaker Switch P.C.B. Assy . . . 11
6. 4. Volume Indicator P.C.B. Assy 12
6. 5. System Remote P.C.B. Assy . . . 12
6. 6. Volume P.C.B. Ass'y ........ 12
6. 7. Display 8: Control P.C.B. ASSy . 12
6. 8. Main P.C.B. Ass'y .......... 13
7. Schematic Diagrams .......... . . ..... 15
7. 1. IC Block Diagrams .......... . . . . . . . . . . 15
7. 2. Schematic Diagrams ............. . . .............. . .............. . ........ 17
(1) Tuner Section ...... . . . 17
(2) Amplifier Section . . . 18
8. Wiring Diagram . . . . . . ........................ 19
9. Block Diagrams . . .............. . . . . 20
9. 1. Tuner 8: Display Control Section ........ 20
9. 2. Amplifier Section .......... . 21
10. Specifications ........... . ............. 22
1. GENERAL
1.1. Production No.
Production No.: D112
1.2. Destinations
USA, CAN, EP, UK, AUS, OTR, JPN
Abbreviation
USA - U.S.A. AUS - Australia
CAN - Canada OTR - Other
EP -- Europe JPN - Japan
UK - United Kingdom
1.3. Parts Supply
(1) Unstocked Parts
Parts marked with 1* at the head of part No. are not
stocked. So, it takes time to supply the parts after we
receive your order.
(2) Unsupplied Parts
Parts without part Nos. (indicated as ~-" in the parts
list) are not supplied.
1.4. CAUTIONSIWARNINGS
(1) Product Safety Notice
Parts marked with the symbol A in the schematic
diagram have critical characteristics.
Use ONLY replacement parts recommended by the
manufacturer.
It is recommended that the unit be operated from a
suitable DC supply or batteries during initial check-out
procedures.
(2) Leakage Current Check/Resistance Check .
Before returning the unit to the customer, make sure you
make either (1) a leakage current check or (2) a line to
chassis resistance check. If the leakage current exceeds 0.5
milliamp, or if the resistance from chassis to either side of
the power cord is less than 240 k ohms, the unit is
defective.
WARNING - DO NOT return the unit to the customer
until the problem is located and corrected.
