Page 1
2
OSHA GUIDELINES FOR NOISE EXPOSURE LIMITS
The Occupational Safety Health Administration (OSHA) has issued
headphone usage recommendations for maximum daily exposure and
sound pressure levels [measured in decibels (dB)]. A decibel is a unit\
of sound measurement that increases exponentially with volume. For
example, conversational speech is typically around 60dB, and a rock
concert in a stadium is often about 110dB.
90dB8 hours
95dB 4 hours
100dB 2 hours
105dB 1 hour
110dB 30 minutes
115dB 15 minutes
120dB Avoid as damage may occur
FCC NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject\
to the following two conditions: (1) this device may not cause harmful\
interference, and (2) this device must accept any interference receive\
d,
including interference that may cause undesired operation.
WARNING!
- Warnings or announcements may be unnoticed when you are
using the headphones. You should be aware of ambient sounds
while wearing the headphones, and recognize them as needed.
- Long-term exposure to loud music may cause permanent hearing
damage.
- Do not attempt to modify this product as it could result in
personal injury and/or product failure.
- If water or other foreign substances permeate inside the device,
fire or electric shock may result. CAUTION
Changes or modifications to this equipment not expressly approved
by NAD Electronics for compliance could void the users authority to \
operate this equipment.
NOTES ON ENVIRONMENTAL PROTECTION
At the end of its useful life, this product must not be disposed
of with regular household waste but must be returned to a
collection point for the recycling of electrical and electronic
equipment. The symbol on the product, users manual and
packaging point this out.
The materials can be reused in accordance with their markings. Through
re-use, recycling of raw materials, or other forms of recycling of old
products, you are making an important contribution to the protection of \
our environment.
Your local administrative office can advise you of the responsible waste\
disposal point.
IMPORTANT SAFETY INSTRUCTIONS
2
ENGLISH
Page 2
3
INTRODUCTION
The NAD VISO HP20 In-Ear Headphones have been designed to bring
the warm, open sound of live performances directly to your personal
headphone experience.
Designed and driven by audiophiles, NAD VISO HP20 is made specifically
for digital natives who understand the difference what clean, crisp
sound makes to music lovers.
The NAD VISO HP20 benefits from true headphone innovation that lets
you sense the music around you, feel every beat, and hear a more open
soundstage.
We hope you will read through this owners guide to help assure that \
you are getting the most out of your new NAD VISO headphones.
For warranty information contact your local distributor.
NAD SHALL NOT BE HELD LIABLE FOR ANY TECHNICAL OR USER
INTERFACE DISCREPANCIES IN THIS MANUAL.
THE VISO HP20 OWNERS MANUAL MAY BE SUBJECT TO CHANGE
WITHOUT PRIOR NOTICE. CHECK OUT THE NAD WEBSITE FOR THE
LATEST VERSION OF THE VISO HP20 OWNERS MANUAL. WHATS INSIDE THE BOX
Packed with your VISO HP20 you will find:
- Replaceable gel inserts in 5 sizes
- Mini-accessory travel pouch
- Cable clip
- 3.5 to ¼ inch headphone adaptor
- Airline adaptor
3
ENGLISH
Page 3
4
1 AIRLINE ADAPTOR
- Use the supplied dual 3.5mm airline adaptor to connect your VISO
HP20 with in-flight entertainment systems.
NOTES
- Audio output jack configurations may vary on airplanes. Airline
audio may not equal the high quality sound heard from your
home audio equipment or portable source.
- NAD Electronics does not recommend using these headphones
as aviation communication equipment as they are not engineered
for many environmental conditions common in commercial or
non-commercial aircrafts (including, but not limited to: altitude,
temperature, noise conditions, unpressurized aircraft, etc.)
resulting in possible interference to critical communications.
2 HEADPHONE ADAPTOR (3.5 mm to ¼ inch)
- Use this headphone adaptor to connect your 1/8 inch (3.5mm)
stereo plug to a 1/4 inch (6.3mm) stereo jack.
3 INLINE MICROPHONE AND REMOTE CABLE
- VISO HP20 is equipped with an inline microphone and remote
cable for use with various models of iPod and other iOS devices.
The cable is equipped with a call answer button and other phone
features for effortless switching between music listening and
talking. It also features music and video playback control for iPod,
iPhone and iPad.
- Audio is supported on all iPod models.
- The remote is supported by iPod Shuffle
(3rd generation and later).
- The remote and microphone are supported only by
- iPod nano (4th generation and later)
- iPod Classic (120GB, 160GB)
- iPod Touch (2nd generation and later)
- iPhone 3S, iPhone 4, iPhone 5, iPad and iPad mini
USING APPLE CONTROL FEATURES
FEATURE PROCEDURE
Answer or end call Press the centre button once to
answer or end a call.
Decline incoming call Press and hold the centre button
for two seconds, then release.
There will be two beeps to
indicate successful operation.
Use call waiting To switch to an incoming call and
put an in-progress call on hold,
press the centre button, and
then repeat to switch back to the
previous call and put the new call
on hold.
To switch to an incoming call and
end an in-progress call, press and
hold the centre button for two
seconds. Two beeps will indicate
successful operation.
Activate Siri or voice
control Press and hold the centre button
for two seconds.
Play/pause song or video Press the centre button to play or
pause the song.
Skip to next/previous song
or chapter Quickly press the centre button
twice to skip to the next song.
Scan forward through
song or video Quickly press, then press and
hold the center button to scan
forward. Release to stop scanning
forward.
Scan backward through
song or video Quickly press twice, then press
and hold the centre button.
Release to stop scanning
backward.
Control Volume Press the ( + ) button to increase
volume. Press the ( - ) button to
decrease volume.
NOTE
Some functions may not be applicable to your iPod or iOS device.
IDENTIFICATION OF PARTS AND ACCESSORIES
ENGLISH
