Page 1
NA D
2
Warning: To reduce the risk of fire or electric shock, do not expose this
unit to rain or moisture.
The lightning flash with an arrowhead symbol within an equilateral trian-
gle is intended to alert the user to the presence of uninsulated danger-
ous voltage within the products enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the product.
Do not place this unit on an unstable cart, stand or tripod,
bracket or table. The unit may fall, causing serious injury to a
child or adult and serious damage to the unit. Use only with a
cart, stand, tripod, bracket or table recommended by the man-
ufacturer or sold with the unit. Any mounting of the device on a
wall or ceiling should follow the manufacturers instructions
and should use a mounting accessory recommended by the
manufacturer.
An appliance and cart combination should be moved with care. Quick stops,
excessive force and uneven surfaces may cause the appliance and cart combi-
nation to overturn.
Read and follow all the safety and operating instructions before connecting or
using this unit. Retain this notice and the owners manual for future reference.
All warnings on the unit and in its operating instructions should be adhered to.
Do not use this unit near water; for example, near a bath tub, washbowl, kitchen
sink, laundry tub, in a wet basement or near a swimming pool.
The unit should be installed so that its location or position does not interfere with
its proper ventilation. For example, it should not be situated on a bed, sofa, rug
or similar surface that may block the ventilation openings; or placed in a built-in
installation, such as a bookcase or cabinet, that may impede the flow of air
through its ventilation openings.
The unit should be situated from heat sources such as radiators, heat registers,
stoves or other devices (including amplifiers) that produce heat.
The unit should be connected to a power supply outlet only of the voltage and
frequency marked on its rear panel.
The power supply cord should be routed so that it is not likely to be walked on or
pinched, especially near the plug, convenience receptacles, or where the cord
exits from the unit.
Unplug the unit from the wall outlet before cleaning. Never use benzine, thinner
or other solvents for cleaning. Use only a soft damp cloth.
The power supply cord of the unit should be unplugged from the wall outlet when
it is to be unused for a long period of time.
Care should be taken so that objects do not fall, and liquids are not spilled into
the enclosure through any openings.
This unit should be serviced by qualified service personnel when:
A. The power cord or the plug has been damaged; or
B. Objects have fallen, or liquid has been spilled into the unit; or
C. The unit has been exposed to rain or liquids of any kind; or
D. The unit does not appear to operate normally or exhibits a marked change in
performance; or
E. The device has been dropped or the enclosure damaged.
DO NOT ATTEMPT SERVICING OF THIS UNIT YOURSELF.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
Upon completion of any servicing or repairs, request the service shops assur-
ance that only Factory Authorized Replacement Parts with the same characteris-
tics as the original parts have been used, and that the routine safety checks
have been performed to guarantee that the equipment is in safe operating condi-
tion.
REPLACEMENT WITH UNAUTHORIZED PARTS MAY RESULT IN FIRE,
ELECTRIC SHOCK OR OTHER HAZARDS.
ATTENTION POUR ÉVITER LES CHOC ELECTRIQUES, INTRODUIRE LA LAME
LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPON-
DANTE DE LA PRISE ET POUSSER JUSQUAU FOND.
CAUTION
TO PREVENT ELECTRIC SHOCK MATCH WIDE BLADE OF PLUG
TO WIDE SLOT FULLY INSERT.
If an indoor antenna is used (either built into the set or installed separately),
never allow any part of the antenna to touch the metal parts of other electrical
appliances such as a lamp, TV set etc.
CAUTION
POWER LINES
Any outdoor antenna must be located away from all power lines.
OUTDOOR ANTENNA GROUNDING If an outside antenna is connected to your tuner or tuner-preamplifier, be sure
the antenna system is grounded so as to provide some protection against volt-
age surges and built-up static charges. Section 810 of the National Electrical
Code, ANSI/NFPA No. 70-1984, provides information with respect to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to
an antenna discharge unit, size of grounding conductors, location of antenna dis-
charge unit, connection to grounding electrodes and requirements for the
grounding electrode.
a. Use No. 10 AWG (5.3mm2) copper, No. 8 AWG (8.4mm2) aluminium, No. 17
AWG (1.0mm2) copper-clad steel or bronze wire, or larger, as a ground wire.
b. Secure antenna lead-in and ground wires to house with stand-off insulators
spaced from 4-6 feet (1.22 - 1.83 m) apart.
c. Mount antenna discharge unit as close as possible to where lead-in enters
house.
d. Use jumper wire not smaller than No.6 AWG (13.3mm2) copper, or the equiva-
lent, when a separate antenna-grounding electrode is used. see NEC Section
810-21 (j).
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL
CODE INSTRUCTIONS CONTAINED IN ARTICLE 810 - RADIO AND TELEVI-
SION EQUIPMENT.
NOTE TO CATV SYSTEM INSTALLER:This reminder is provided to
call the CATV system installers attention to Article 820-22 of the
National Electrical Code that provides guidelines for proper grounding
and, in particular, specifies that the ground cable ground shall be con-
nected to the grounding system of the building, as close to the point of
cable entry as practical.
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
ATTENTION:RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL
IMPORTANT SAFETY INSTRUCTIONS
Page 2
NA D
3
WARNING - INVISIBLE LASER RADIATION WHEN OPEN AND
INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM.
VORSICHT! - UNSICHTBARE LASERTRAHLUNG TRITT AUS,
WENN DECKEL GEÖFFNET UND WENN SICHERHEITSVERRIEGELUNG
ÜBERBRÜCKT IST. NICHT DEM STRAHL AUSSETZEN.
ADVARSEL - USYNLIG LASERSTRÅLING VED ÅBNING, NÅR
SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION. UNDGÅ
UDSÆTTELSE FOR STRÅLING.
ADVARSEL - USYNLIG LASERSTRALING NÅR DEKSEL ÅPNES OG
SIKKERHEDSLÅS BRYTES. UNNGÅ EKSPONERING FOR STRÅLEN.
VARING - OSYNLING LASERSTRÅLNING NÄR DENNA DEL ÄR
ÖPPNAD OCH SPÄRRAR ÄR URKOPPLADE. STRÅLEN ÄR FARLIG.
VARO! - AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET
ALTTINA NÄKTMÄTONTÄ LASERSÄTEILYLLE. ÄLÄ KAISO SÄTEESEEN.
CLASS 1 LASER PRODUCT
LUOKAN 1 LASERPLAITE
KLASS 1 LASERAPPARAT
THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS B
LIMITS FOR RADIO NOISE EMISSIONS FROM DIGITAL APPARA-
TUS AS SET OUT IN THE RADIO INTERFERENCE REGULATIONS
OF THE CANADIAN DEPARTMENT OF COMMUNICATIONS.
LE PRESENT APPAREIL NUMVERIQUE NEMENT PAS DE
BRUITS RADIOELECTRIQUES DEPASSANT LES LIMITES
APPLICABLES AUX APPAREILS NUMERIQUES DE LA CALSSE B
PRESCRITES DANS LE REGLEMENT SUR LE BROUILLAGE
RADIO ELECTRIQUE EDICTE PAR LE MINISTERE DES COMMU-
NICATIONS DU CANADA.
SAFETY WARNING
Manufactured under license from Dolby Laboratories. Dolby, Pro Logic and the Double-D symbol are trade-
marks of Dolby Laboratories. Confidential unpublished works. ©1992-1997 Dolby Laboratories, Inc. All rights
reserved.
Page 19
NA D
20
GB
- The T 761 allows the volume of each speaker to
be individually trimmed so that none of the speakers
dominates in playback and detracts from the sur-
round illusion.
- Highlight the required speaker and adjust with 1
cursor to decrease and 2cursor to increase the level.
Each speaker can be adjusted within a -10 to +10dB
range.
- Highlight SAVE & EXIT and press ENTERto save
the settings and return to the SETUP menu.
NOTES:
The CHANNEL BALANCE menu in OSD can also
be accessed directly with the LEVELSandTESTbut-
tons on the remote for setting adjustment. (Refer also
to chapter Remote Control).
3. CHANNEL DELAYS
- Highlight CHANNEL DELAYS in the SETUP
menu and press ENTER on the remote. You will see
a screen similar to the following:
- Use the 1or 2cursor button to change the center
channel delay time.
In Dolby Digital mode, T 761 allows the following
setting options:
CENTER 0, 1, 2, 3, 4 & 5ms
REAR 0, 1, 2, 3, ...... 13, 14, 15ms
(1ms per step)
In Dolby Pro logic mode, only the rear channel
delay time can be adjusted as following options:REAR 15, 16, 17, ...... 28, 29, 30ms
(1ms per step)
For other modes, the channel delay time cannot be
adjusted.
- Highlight SAVE & EXIT and press ENTERto save
the settings and return to the SETUP menu.
Otherwise, select DO NOT SAVE & EXIT to leave
without saving any changes.
4. SPEAKER SETTINGS
The size and number of speakers can be described
in the SPEAKER SETTINGS menu. Highlight
SPEAKER SETTINGS in the SETUP menu and press
ENTERon the remote. You will see a screen similar
to the following:
The description LARGE and SMALL mean the fol-
lowing:
The LARGE mode is used when the speaker is full
range and capable of reproducing the entire audible
frequency spectrum 20Hz to 20kHz.
The SMALL mode is used when the speaker is not
capable of reproducing the deepest bass portion of
the audio frequency 20Hz to 100Hz.
You are given the following choices:
- MAIN
For the left and Right speakers, you can select
Large or Small. When Small is selected, the deepest
bass portion is re-directed to the subwoofer.
- CENTER
You can choose Large, Small or Off. When Small
is selected, the deepest bass portion is re-directed to
the subwoofer. With Off selected, all information for
the Center channel will be equally divided over the
Left and Right speakers.
- SURROUND
You can choose Large, Small or Off. When Small
is selected, the deepest bass portion is re-directed to
the subwoofer. With Off selected, all information for
the Surround channels will be equally divided over
the Left and Right speakers.
- SUBWOOFER
You can choose ON and OFF. With Subwoofer
set to ON, the LFE (Low Frequency Effects) channel
MAIN : LARGE/SMALL
CENTER : LARGE/SMALL/OFF
SURROUND : LARGE/SMALL/OFF
SUBWOOFER : ON/OFF
DO NOT SAVE & EXIT
SAVE & EXITSPEAKER SETTINGS
CENTER OmS
REAR OmS
DO NOT SAVE & EXIT
SAVE & EXITCHANNEL DELAYS
LEFT : 0dB
CENTER : 0dB
RIGHT : 0dB
REAR L : 0dB
REAR R : 0dB
SUB : 0dB
DO NOT SAVE & EXIT
SAVE & EXITCHANNEL BALANCE
