Nad T 524 Owners Manual

Page 1

WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER OR BACK OF THIS PRODUCT. THERE ARE NO USER- SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO DRIPPING OR SPLASHING WATER, RAIN, OR MOISTURE. DO NOT PLACE OBJECTS FILLED WITH WATER SUCH AS VASES, ON THE PRODUCT. WARNING: THIS DIGITAL VERSATILE DISC PLAYER EMPLOYS A LASER SYSTEM. USE OF CONTROLS, ADJUSTMENTS, OR THE PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. WARNING: TO PREVENT DIRECT EXPOSURE TO LASER BEAM, DO NOT OPEN THE ENCLOSURE. VISIBLE LASER RADIATION WHEN OPEN. WARNING: NEVER STARE DIRECTLY INTO THE LASER BEAM. CAUTION DO NOT INSTALL THIS PRODUCT IN A CONFINED SPACE SUCH AS A BOOK CASE OR SIMILAR UNIT. This product is manufactured to comply with the radio interference requirements of EEC DIRECTIVE 89/336/EEC, 93/68/EEC and 73/23/EEC. NOTES ON COPYRIGHT It is forbidden by law to copy, broadcast, show, broadcast via cable, play in public, or rent copyrighted material without permission. This product features the copy protection function developed by Macrovision. Copy protection signals are recorded on some discs. When recording and playing the pictures of these discs picture noise will appear. This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited. CONSUMERS SHOULD NOTE THAT NOT ALL HIGH DEFINITION TELEVISION SETS ARE FULLY COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN CASE OF 525 OR 625 PROGRESSIVE SCAN PICTURE PROBLEMS, IT IS RECOMMENDED THAT THE USER SWITCH THE CONNECTION TO THE STANDARD DEFINITION OUTPUT. IF THERE ARE QUESTIONS REGARDING OUR TV SET COMPATIBILITY WITH THIS MODEL 525p AND 625p DVD PLAYER, PLEASE CONTACT OUR CUSTOMER SERVICE CENTER. SERIAL NUMBER: You can find the serial number on the back of the unit. This number is unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase. MODEL NO. ____________________________ SERIAL NO. ____________________________ DATE OF PURCHASE _________________________ SAFETY PRECAUTIONS Introduction ENGLISH FRANÇAIS DEUTSCHNEDERLANDS ESPAÑOLITALIANO PORTUGUÊS SVENSKA NAD is a trademark of NAD Electronics International, a division of Lenbrook Industries Limited Copyright 2004, NAD Electronics International, a division of Lenbrook Industries Limited CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN T524C_NAD_English_Final.qxd 1/25/05 2:48 PM Page 2

Page 2

3 INTRODUCTION Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\ . .2 Before use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\ . . . . . . . . .4Symbol used in this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 About the ( ) Symbol Display . . . . . . . . . . . . . . . . . . . . . . . . . .4 Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\ . . . .4 Types of Playable Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 Disc-related terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\ .6 Front Panel and Display Window . . . . . . . . . . . . . . . . . . . . . . . . .7 Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\ . . . . . . . . .8 Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\ . . . .9 INSTALLATION AND SETUP Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\ . . . . . .10 Setting up the Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 DVD Player Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 Audio Connection to Optional Equipment . . . . . . . . . . . . . . . . .11 Before operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\ . .11 On-Screen Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\ 12 Initial Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\ . . .13 Language. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \ . . . . . . . 13 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \ . . . . . . . . . 13 AUDIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \ . . . . . . . . . 14 Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \ . . . . . . . . . 15 LOCK (Parental Control) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 OPERATION Operation with DVD and Video CD . . . . . . . . . . . . . . . . . . . . . . .17Playing a DVD or Video CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 General Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\ .17 Special DVD Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 DVD Audio Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\ .20 Operation with Audio CD and MP3 / WMA Disc . . . . . . . . . . . .21 Playing an Audio CD or MP3/WMA Disc . . . . . . . . . . . . . . . . . . .21 Audio CD and MP3 / WMA Disc Features . . . . . . . . . . . . . . . . . .22 Programmed Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 Operation with JPEG Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 Viewing a JPEG Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 Operation with a DVD VR format Disc . . . . . . . . . . . . . . . . . . . .25 Maintenance and Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 Operation with a DivX Movie Disc . . . . . . . . . . . . . . . . . . . . . . .26 Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 Additional Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27\ Speaker Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\ . . . .28 REFERENCE Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\ . . .29 Table of Languages and their Codes . . . . . . . . . . . . . . . . . . . . . .30 Country Codes List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\ .31 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\ . . . . .32 TABLE OF CONTENTS Introduction ENGLISH FRANÇAIS DEUTSCH NEDERLANDS ESPAÑOL ITALIANO PORTUGUÊS SVENSKA T524C_NAD_English_Final.qxd 1/25/05 2:48 PM Page 3

Page 19

20 ENGLISH FRANÇAISDEUTSCHNEDERLANDS ESPAÑOLITALIANO PORTUGUÊS SVENSKA DVD AUDIO DISCS DVD Audio is a new disc format building on the success of DVD to provide high quality, uncompressed, multi-channel audio for a new experience in audio quality. A DVD Audio disc can be identified by the DVD audio logo on the disc jacket or on the disc itself. DVD Audio can provide higher quality stereo than Audio CDs with a sampling rate of up to 192 kHz (compared to 44.1 kHz for CDs). DVD Audio digital sound can be delivered with up to 24 bits of data (compared to 16 bits for a standard CD). A typical DVD Audio disc contains up to seven times the data capacity of a CD. This additional space is used for music, either Advanced Resolution multi- channel sound quality that is closer to the artist\ s master recording or for longer recordings. Many DVD Audio discs contain on-screen text, such as artist biographies, playlists, or lyrics. Some DVD Audio discs contain photo galleries or video clips. NOTE To enjoy maximum sound quality and surround effect of DVD Audio, you must use 5.1 channel analogue audio output (5.1CH AUDIO OUT jacks on the DVD Player). If you use the DIGITAL OUT (OPTICAL or COAXIAL) for your audio connection, the sound will only be similar to CD-quality sound even though youre playing a DVD Audio disc. MOVING TO ANOTHER GROUP Some DVD Audio discs divide content into different groups. Your player enables you to quickly access different groups during playback via the on-screen display. 1 Press DISPLAY during playback on in stop mode. 2 Press to select Group icon. 3 Press or the numbered buttons (0-9) to select a group number. NOTE Sometimes the author of the disc creates hidden content that can only be accessed by entering a password. If the lock icon appears on the TV screen, enter the password (sometimes youll find it on the discs jacket cover or on a web site). This password control isnt dictated by your DVD Player - it is a function of the disc. Since the authoring of DVD Audio Discs varies, some of the on-screen display choices might not be available for the disc youre playing. VIEWING ANOTHER PAGE Since DVD Audio discs can hold a lot of content, there are various ways to see whats available on the disc. 1 Press DISPLAY during playback. 2 Press to select Page icon. 3 Press to select a page number. What appears on the screen will vary from disc to disc because the information available depends upon the way the disc was created. NOTE Since the authoring of DVD Audio Discs varies, some of the on-screen display choices might not be available for the disc youre playing. OPERATION WITH DVD AND VIDEO CD Operation T524C_NAD_English_Final.qxd 1/25/05 2:48 PM Page 20

Page 25

26 ENGLISH FRANÇAIS DEUTSCH NEDERLANDSESPAÑOLITALIANO PORTUGUÊSSVENSKA Using this DVD Player you can play DivX discs. 1Insert a disc and close the tray. The MOVIE menu appears on the TV screen. 2Press to select a folder, and press ENTER. A list of files in the folder appears. If you are in a file list and want to return to the Folder list, use the buttons on the remote to highlight and press ENTER. 3If you want to view a particular file, press to highlight a file and press ENTER or PLAY. 4Press STOP to exit. TIP - Press DVD MENU to move to the next page. - On a CD with MP3/WMA, JPEG and MOVIE files, you can switch to the MUSIC, PHOTO and MOVIE menu. Press TITLE and MUSIC, PHOTO and MOVIE at the top of the menu is highlighted.DIVX DISC COMPATIBILITY WITH THIS PLAYER IS LIMITED AS FOLLOWS: - Available resolution size of the DivX file is under 720x576 (W x H) pixels. - The file name of the DivX subtitle is available up to 56 characters. - If there is an impossible code to express the DivX file, it may be displayed as " _ " mark on the display. - If the number of screen frames is over 30 per 1 second, this unit may not operate normally. - If the video and audio structure of the recorded file is not interleaved video, audio or both may not be outputted. - If the file is recorded with GMC, the unit supports only 1-point of the record level. * GMC? GMC is the acronym for Global Motion Compensation. It is an encoding tool specified in MPEG4 standard. Some MPEG4 encoders, like DivX or Xvid, have this option. There are different levels of GMC encoding, usually called 1-point, 2-point, or 3-point GMC. Playable DivX files - - ".avi ", ".mpg ", ".mpeg " Playable Codec formats - - "DIVX3.xx ", "DIVX4.xx ", "DIVX5.xx ", "XVID ", "MP43 ", "3IVX ". Playable Audio format - - "AC3 ", "DTS ", "PCM ", "MP3 ", "WMA ". - Sampling frequency: within 8 - 48 kHz (MP3), within 32 - 48 kHz (WMA) - Bit rate: within 8 - 320kbps (MP3), 32 - 192kbps (WMA) OPERATION WITH A DIVX MOVIE DISC Operation ListMovie Folder 1Movie Folder 2Movie Folder 3Movie Folder 4Movie Folder 5Movie Folder 6Movie Folder 7Movie Folder 8 MOVIE0:00:00 T524C_NAD_English_Final.qxd 1/25/05 2:48 PM Page 26

Page 30

31 ENGLISH FRANÇAIS DEUTSCH NEDERLANDS ESPAÑOL ITALIANO PORTUGUÊS SVENSKA Reference COUNTRY CODE LIST Choose a country code from this list. Code Country Code Country Code Country Code Country AD Andorra ER Eritrea LC Saint Lucia SC Seychelles AE United Arab Emirates ES Spain LI Liechtenstein SD Sudan AF Afghanistan ET Ethiopia LK Sri Lanka SE Sweden AG Antigua and Barbuda FI Finland LR Liberia SG Singapore AI Anguilla FJ Fiji LS Lesotho SH Saint Helena AL Albania FK Falkland Islands LT Lithuania SI Slovenia AM Armenia FM Micronesia LU Luxembourg SJ Svalbard and AN Netherlands Antilles FO Faroe Islands LV Latvia Islands Jan Mayen AO Angola FR France LY Libya SK Slovak Republic AQ Antarctica FX France (European MA Morocco SL Sierra Leone AR Argentina Territory) MC Monaco SM San Marino AS American Samoa GA Gabon MD Moldavia SN Senegal AT Austria GB Great Britain MG Madagascar SO Somalia AU Australia GD Grenada MH Marshall Islands SR Suriname AW Aruba GE Georgia MK Macedonia ST Saint Tome and Principe AZ Azerbaidjan GF French Guyana ML Mali SU Former USSR BA Bosnia-Herzegovina GH Ghana MM Myanmar SV El Salvador BB Barbados GI Gibraltar MN Mongolia SY Syria BD Bangladesh GL Greenland MO Macau SZ Swaziland BE Belgium GM Gambia MP Northern Mariana Islands TC Turks and Caicos Islands BF Burkina Faso GN Guinea MQ Martinique (French) TD Chad BG Bulgaria GP Guadeloupe (French) MR Mauritania TF French Southern BH Bahrain GQ Equatorial Guinea MS Montserrat Territories BI Burundi GR Greece MT Malta TG Togo BJ Benin GS S. Georgia & MU Mauritius TH Thailand BM Bermuda S. Sandwich Isls. MV Maldives TJ Tadjikistan BN Brunei Darussalam GT Guatemala MW Malawi TK Tokelau BO Bolivia GU Guam (USA) MX Mexico TM Turkmenistan BR Brazil GW Guinea Bissau MY Malaysia TN Tunisia BS Bahamas GY Guyana MZ Mozambique TO Tonga BT Bhutan HK Hong Kong NA Namibia TP East Timor BV Bouvet Island HM Heard and McDonald NC New Caledonia (French) TR Turkey BW Botswana Islands NE Niger TT Trinidad and Tobago BY Belarus HN Honduras NF Norfolk Island TV Tuvalu BZ Belize HR Croatia NG Nigeria TW Taiwan CA Canada HT Haiti NI Nicaragua TZ Tanzania CC Cocos (Keeling) Islands HU Hungary NL Netherlands UA Ukraine CF Central African Republic ID Indonesia NO Norway UG Uganda CG Congo IE Ireland NP Nepal UK United Kingdom CH Switzerland IL Israel NR Nauru UM USA Minor Outlying CI Ivory Coast IN India NU Niue Islands CK Cook Islands IO British Indian Ocean NZ New Zealand US United States CL Chile Territory OM Oman UY Uruguay CM Cameroon IQ Iraq PA Panama UZ Uzbekistan CN China IR Iran PE Peru VA Vatican City State CO Colombia IS Iceland PF Polynesia (French) VC Saint Vincent & CR Costa Rica IT Italy PG Papua New Guinea Grenadines CS Former Czechoslovakia JM Jamaica PH Philippines VE Venezuela CU Cuba JO Jordan PK Pakistan VG Virgin Islands (British) CV Cape Verde JP Japan PL Poland VI Virgin Islands (USA) CX Christmas Island KE Kenya PM Saint Pierre and Miquelon VN Vietnam CY Cyprus KG Kyrgyzstan PN Pitcairn Island VU Vanuatu CZ Czech Republic KH Cambodia6 PR Puerto Rico WF Wallis and Futuna Islands DE Germany KI Kiribati PT Portugal WS Samoa DJ Djibouti KM Comoros PW Palau YE Yemen DK Denmark KN Saint Kitts & Nevis Anguilla PY Paraguay YT Mayotte DM Dominica KP North Korea QA Qatar YU Yugoslavia DO Dominican Republic KR South Korea RE Reunion (French) ZA South Africa DZ Algeria KW Kuwait RO Romania ZM Zambia EC Ecuador KY Cayman Islands RU Russian Federation ZR Zaire EE Estonia KZ Kazakhstan RW Rwanda ZW Zimbabwe EG Egypt LA Laos SA Saudi Arabia EH Western Sahara LB Lebanon SB Solomon Islands T524C_NAD_English_Final.qxd 1/25/05 2:48 PM Page 31
