Page 2
Analogue performance
Analogue input impedance
Analogue frequency response
Maximum input level
THD+N
Signal/noise ratio
Dynamic Range
Analogue channel separation
Crosstalk
Maximum output level
Output impedance
Main pre-out
Tape out
Multi-room output
Tone Controls
Bass
Treble
Digital input performance
THD+N (Bandwidth 10Hz - 20kHz)
Video Section
Input and output impedance
Component Video Bandwidth
Composite and S-Video
Tuner Section
Input sensitivity Mono
50dB Stereo:
Harmonic Distortion; FM Mono
Harmonic Distortion; FM Stereo
Signal/noise; Mono
Signal/noise; Stereo
Stereo separation at 1kHz
Frequency response; + 1.5dB
Physical Specifications
Dimensions (W x H x D)
Net Weight
Shipping Weight
15K /100pF
5Hz to 20K -/±0.8dB
8V
0.008%
>90dB
95dB
70dB
70dB
5V
150 ohms
330 ohms
330 ohms
±10dB
±10dB
0.008%
75-„¦
50MHz
-‰¥ 12MHz
16.1dBf
36.1dBf
0.25%
0.5%
60dB
55dB
40dB
30Hz - 15kHz
17 1/8 x 5 15/16 x 15 3/8
(435 x 150 x 399 mm)
17.6 lbs (8kg)
22.4 lbs (10.2kg)
