the M4 to be fully integrated with advanced automated
control systems.
The clear two line dot matrix display shows information
about the broadcasts being received, which may include
station ID and song and artist information.VALUE
Compared with other tuners of similar performance and
capability the M4 stands apart for its superb style, build
quality and affordable price.
FM Tuner Section
Tuning Range
(0.0125MHz steps)
Usable Sensitivity
Signal/Noise Ratio
Mono
Stereo
Frequency Response
(20 Hz - 15 kHz)
Channel Separation
30 Hz
1 kHz
10 kHz
Capture Ratio
AM Suppression
Image Rejection
I.F. Rejection
Pilot Suppression
AM Tuner Section
Tuning Range
North America
(10kHz steps)
Europe (9kHz steps)
Usable Sensitivity
S/N Ratio
Total Harmonic Distortion
IF Rejection
Image Rejection
Selectivity
Loop Sensitivity
999 /1000 kHz
603/600 kHz
1404/1400 kHz
Frequency response
Audio Output DAB Tuner Section - Band III
Tuning Range
Maximum input signal
Usable Sensitivity
Far-off Selectivity
Adjacent Channel rejection
Total Harmonic Distortion
S/N Ratio
Frequency Response
Sampling Frequency
DAB Tuner Section - Band L
Tuning Range
Maximum input signal
Usable Sensitivity
Far-off Selectivity
Adjacent Channel rejection
Total Harmonic Distortion
S/N Ratio
Frequency Response
Sampling Frequency
Physical Specifications
Net Dimensions (W x H x D)
Gross Dimensions*
Net Weight
Shipping Weight
87.5MHz - 108.5MHz
13 dBμ
72 dB
66 dB
±1.0 dB
33 dB
42 dB
32 dB
3 dB
65 dB
85 dB
78 dB
60 dB
530kHz - 1710Mhz
531kHz - 1602Mhz
30dBμ
38dB
3%
36dB
28dB
17dB
66dB
66dB
66dB
±6 DB
130 mV ±20mV 174MHz -“ 240MHz
-10 dBm
-100dBm typical
40dB
40dB
0.01%
100dB
±0.3dB
48kHz
1452 - 1492MHz
-16 dBm
-97dBm typical
40dB
40dB
0.01%
100dB
0.3dB
48kHz
17 1/8 x 3 7/8 x 11 4/5
(435 x 100 x 300mm)
17 1/8 x 4 1/2 x 12 1/4
(435 x 115 x 312mm)
19.75 lbs (8.97kg)
31.5 lbs (14.3kg)
Specifications
*includes volume knob, speaker terminals, connectors
& feet. Note: Installers should allow a minimum clear
-
ance of 4 inches for wire management.
