© NAD 2004 L53 GNDAM POWER Serial No./ No. De Series COMPONENT VIDEO OUT � Cr/Pr Cb/ Pb Y DIGITAL OUTPUT DIGITAL INPUTS IN IR COAXIAL OPTICAL ANTENNA FM CAB / SAT IN IN L R VCR IN IN VIDEO S-VIDEO OUT SUBW PRE-OUT OUT MONITOR OUT SPEAKERSR L CAUTION: SPEAKER IMPEDANCE 8 OHM MIN./ SPEAKER SWITCHED 100 WATTS MAX AC OUTLET NAD Electronics International reserves the right to change specifi cations or features without notice. NAD is a registered trademark of NAD Electronics International. All rights reserved. No part of this publication may be reproduced, stored, or tr ansmitted in any form whatsoever without the written permission of NAD Electronics International. © 08/04 NAD Electronics International. www.NADelectronics.com Amplifier Section Power output stereo mode IHF dynamic power; 8 - Total harmonic distortion at rated power IM distortion at rated power Damping factor 8- Input sensitivity and impedance Frequency response Signal/noise ratio (ref rated power/8- (A-WTD)) Signal/noi se ratio (ref 1W/8- (A-WTD)) Remote Control FM Tuner Section 50dB Quieting Sensitivity; FM Mono 50dB Quieting Sensitivity; FM Stereo Image Rejection Harmonic Distortion; FM Mono Harmonic Distortion; FM Stereo Signal/noise; Mono Signal/noise; StereoSignal/noise; Stereo Channel Separation at 1kHz Frequency response; ±1.5dB AM Tuner Section Usable Sensitivity Selectivity Image Rejection IF Rejection Signal/Noise Ratio Harmonic Distortion 2 x 50W 2 x 82W 0.08% 0.08% >60 200mV / 50k- 20 to 20,000 Hz +/- 0.5 dB >99 dB >85dB HTR L53 -16 dBf -36.1 dBf >50dB 0.2% 0.5% 69 dB 64.2dB 40dB 30Hz - 15kHz 55dBuV 25dB 35dB 50dB 55dB 0.8% Audio Frequency Response CD Audio Signal to noise ratio, A-weighted THD (at 0dB, 1kHz) Wow and Flutter Channel separation CD Dynamic range DVD Video Signal to Noise Signal system Inputs Digital coaxial - PCM, DTS, AC3 Digital optical - PCM, DTS, AC3 IR Input Outputs Digital optical - PCM, DTS, AC3 Composite Video S-Video Physical Specifi cations Dimensions (W x H x D)* Net Weight Shipping Weight 10Hz -22kHz >85dB T0.008% Quartz accuracy 86dB 103dB 62dB PAL/NTSC RCA x 1 TOS Link x 1 Yes TOS Link x 1 RCA x 1 Y/C 4 pin x 2Y/C 4 pin x 2 Yes 17 1/8 x 3 1/2 x 13 (435 x 89 x 320 mm) 18.5 lbs (8.4 kg) 22.7 lbs (10.3 kg) * Dimensions are of units cabinets without feet attached; add up to 18mm for total height. Dimension depth excludes terminals, sockets, controls and buttons.
