Nad C 370 Service Manual

Page 2

TABLE OF CONTENTS

DESCRIPTION PAG E.
REAR PANEL/FRONT PANEL VIEW ................................................ 3
SPECIFICATIONS ...................................................................... 4-5
ALIGNMENT PROCEDURE.....................................................6-7
PCB LAYOUT ............................................................................ 8-9 .
WIRING DIAGRAM ...................................................................... 10
SCHEMATIC DIAGRAM .......................................... y ......... 11-12
ELECTRICAL PARTS LIST .................................... ............... 13-17 ,
EXPLODED VIEW PARTS LIST ........... ..................................... 18
EXPLODED VIEW ...................... , .......................................... I .19
PACKING DIAGRAM ........................................ ....................... 20

jERVICE SAFETY PRECAUTIONS

1. Replacing the fuses
CAUTION: FOR CONTINUED PROTECTION AGAINST THE RISK OP FIRE, REPLACE ONLY WITH
DESIGNATED TYPE OF FUSE FOR AH, *BI. 35 AND *C VERSIONS.

Reference NO Part Number Description

F701'B1,*B&C 20-00400-25 T4AH 230v _ _
F701 *AH 20-00630-25 T6.3AH 250v
NOTE:

<*AH> : USA, CANADIAN MODEL ONLY.
<*B> : UK MODEL ONLY.

: AUSTRALIAN MODEL ONLY.
<*C> : EUROPEAN MODEL ONLY.

2. Safety check out
(Only U.S.A. Model)
Before returning the product to the customer, make leakage current or resistance measurements to
determine that exposed parts are acceptably Insulated from the supply circuit.

Parts marked with the symbol AWe critical with regard to the risk of fire and electric shock. Replace
only with parts recommended by the manufacturer.
