Nad 316 Service Manual

Extracted text from Nad 316 Service Manual (Ocr-read)

Page 1

NAD 316 SERVICE HINT PROBLEM: A buzz is audible in the centre and rear channel. CAUSE: Not proper grounding of the amplifier. SOLUTION: Cut the shielding of cable to center / rear amplifier (P621) on the volume control PCB side (P621a). Solder on this side a cable directly to the PCB and solder the other end to the grounding of P621b. PRODUCTION: PAGE 3-98-14
