X-PSU
V8
CONTENTS
Issue 1 Page 2 of 10
PAGE
3 Safety information - Safety inf ormation
4 General advi ce -
-
Installation precautions
User infor mation
5 Item di sposal information - EU disposal inform ation
6 Installation -
-
-
-
Introductio n
Installation
Connections
Cleaning
7 Facilities and connection - Illustrations - front and rea r panels
8 Power suppl y problems? - Basic fault finding
9 Power suppl y specifications
10 Manual hist ory
Page 2
X-PSU
V8
SAFETY INFORMATION
Issue 1 Page 3 of 10
IMPORTANT ! (U.K. onl y)
This unit is supplied in the U.K. with ma ins lead fitted with a moul ded 13 am p p lug. If, for any reason, y ou need to cut
off the plug, please re move the fuse holder and dispo se of the plug safely , out of reach of children. It must not be
plugged into a m ains outlet.
The wires in the mains lead supplied with this applia nce are coloured in accordan ce with the following code:
Green and y ellow........ ...... Earth
Blue.......... .... ........ ...... ....N eutral
Brown......... .......... ...... ...... ..Live
WAR NIN G - This appliance MUST b e earthed
As the colours of the wires of the m ains lead of this appliance may not correspo nd with the
coloured m arkings identifying the term inals in your plug, proceed as follows:
The wire which is coloured green-and-y ellow m ust be connected to the term inal in the plug which is marked with the
letter E or coloured green o r green-and- yellow, or b y the earth sy mbol :
The wire which is coloured brown m ust be connected to the te rm inal which is marked with the letter L or coloured red.
The wire which is coloured blue m ust be connected to the te rm inal which is marked with the l etter N or coloured black.
If connecting to a BS1363 plug, a 13 amp fuse m ust b e used.
WARNING:
ANY M ODI FICAT IONS TO THIS P ROD UCT NOT EX PRE SSLY APPR OVE D
BY MUSICAL FIDE LITY WHO IS THE PART Y RESPONSIBLE F OR
STAND AR DS COMPLI ANCE COU LD VOID T HE USE R'S AUT HORIT Y TO
OPERATE THIS EQUIPMENT.
