E50 Instructions For Use. Page 2 IMPORTANT!
This unit is supplied in the UK with a mains lead fitted with a moulded 13 amp
plug. If, for any reason, you need to cut off this plug, please observe the following
safety precautions. Please dispose of the cut-off plug safely. It must not be plugged
into a mains power supply.
The wires in the mains lead supplied with this appliance are coloured in ac-
cordance with the following code:
Green and yellow..............Earth
Blue...............................Neutral
Brown................................Live
WARNING - This appliance must be earthed
As the colours of the wires of the mains lead of this appliance may not corre-
spond with the coloured markings identifying the terminals in your plug, proceed as
follows:
-The wire which is coloured green-and-yellow must be connected to the termi-
nal in the plug which is marked with the letter E or coloured green or green-and-
yellow, or by the earth symbol .
-The wire which is coloured brown must be connected to the terminal which is
marked with the letter L or coloured red.
-The wire which is coloured blue must be connected to the terminal which is
marked with the letter N or coloured black.
-If connecting to a BS1363 plug, a 10 amp fuse must be used.
WARNING - Radio Frequency Interference (RFI)
This hi-fi product has been tested to ensure that its operation will not be ad-
versely affected by normal background levels of RFI. It is possible that if this prod-
uct is subjected to abnormally high levels of RFI the unit may be susceptible and not
perform as expected. In the unlikely event of this happening on a regular basis,
please contact Musical Fidelity's service department.
The unit has also been tested to ensure that it does not radiate excessive levels
of RFI that could affect other pieces of electronic or electrical equipment.
The electronics in modern hi-fi equipment is complex and hence may be dam-
aged by lightning. It is possible that during electrical storms the operation of some
equipment may be adversely affected. For complete protection of your hi-fi system
during such storms, mains plugs should be removed and aerial leads disconnected.
Always ensure that when disconnecting and reconnecting your hi-fi equipment
the mains supply is switched off.PLEASE READ
Page 2
E50 Instructions For Use. Page 3 FACILITIES AND CONNECTIONS1112 1 2
10 9 8 7 6 5 4 3
13141516
FRONT PANEL
1LCD Display Panel
21-10 Push Buttons for Preset
Station Recall
3Power On/Off Push Button
4Tuned Indicator Light
5Auto Tuning Indicator Light
6Tune Down Push Button
7Tune Up Push Button
8Auto/Manual Tuning Mode Push
Button
9Mono/Stereo Reception Mode
Push Button
10Stereo Reception Indicator Light
11Memory Store Push Button
12Preset Memory Scan Push ButtonREAR PANEL
13Aerial Connection (75 ohm unbalanced)
14Right Channel Audio Output
15Left Channel Audio Output
16AC Mains Input
