The Mini Morley Series are quality USA made Electro-
Optical pedals designed to take up less room on your
pedal board or for anytime you need a reliable, great
sounding pedal in a smaller footprint.
MINI MORLEY VOLUME
(Model MMV)
a O 6.75 L x 4.5 Wx 2.75" H
O EIectro-Optiool Volume
'\ (no more pots to wear out!)
n 0 Smooth Audio Taper
0 LED Indimtion
I Powers from one 9V battery
1 « ~ or optional Morley adapter
0 Quick Clip Battery door
0 Cold Rolled Steel housing
0 Two-year warranty
MINI MORLEYWAH
(Model MMW)
O 6.75" L x 4.5 Wx 2.7 " H
O Electra-Optical Wah
(no more pots to wear out!)
0 Vintage III/ah Tone 9,
0 TrueTone Bypass Buffer [y a
0 Wah Level Control 29 I
0 LED Indication
0 Powers from one 9V
battery or optional
Morley 9V adapter
0 Quick Clip Battery door
0 Cold Rolled Steel housing
0 Two-year warranty
MINI MORLEY WAH / VOLUME
(Model MWV)
O 6.75 L x 4.5 Wx 2.7 " H
, ll 0 Electro Optical Wah 8t Volume
(no more pots to wear out!)
5A O Wlltage Wah Tone
4 3 0 Smooth Audio Taper Volume
I TrueTone Bypass Buffer
C Wah Level Control
0 LED Indication
0 Powers from one 9V battery
or optional Morley 9V adapter
0 Quick Clip Battery door
0 Cold Rolled Steel housing
0 Two-year warranty
MINI MORLEY MAVERICK (Model MSW)
6.75" L x 4.5" W x 2.75" H
Switchless Wah
Electra-Optical Wah I.
(no pots to get scratchy) . 4
Hybrid \fintage/Modern Wah ~
LED Indication »
Quick Clip Battery Door p
Powers from one 9V battery
or Optional Morley Adapter
Cold Rolled Steel housing
0 Two-yearwarranty
ABY MIX (Model ABY Mix)
TKHE-Mr-i-Py . Route 2 guitars to 2 amps
a 1 " 5 0 Select / combine amps
0 Independent input level
controls for the perfect mix
(Up to 20dB of clean boost)
0 Active, Buffer Circuit
0 LED Indication
0 Powers from 9V battery
or Morley 9V Adapter
0 Cold Rolled Steel housing
with Quick Clip battery door
I Two-yearwarranty
TWIN MIX (Model Twin Mix)
0 Route 2 guitars to 2 amps
0 Input Mute Switches
0 Use only OutputAto
combine Inputs. Use both
A8. B Outputs to split inputs
0 Independent input level
controls forthe perfect mix
(Up to 20dB of clean boost)
O Adlve, Butler Circuit
0 LED Indication #36
0 Powers from 9V battery or adapter
0 Cold Rolled Steel housing with
Quick Clip battery door
0 Two-year warranty
I .u
mun w-
.W Ml mm 1
A om mg.
B
e ABY <19 Mix
BUFFER BOOST (Model MBB)
0 Our "True-Tone" buffer circuit
maintains level & tone
0 Handy ZDdB boost
0 Power 8: Boost LEDs
0 Cold Rolled Steel housing
with Quick Clip battery door
0 Powers from 9V battery or
optional Money 9V adapter
0 Two-year warranty
EFFECTS LOOP CORRECTOR
(Model ELC)
0 Increase weak FX loop signals
0 Decrease hot FX Loop signal
Prevent Ground Hum & Buzz
w I Accepts Mono (TS) or Stereo
TRS cables in any combination
0 Internal Ground Reference Switch
0 Cold Rolled Steel housing
0 Two-year warranty
ACCU-TUNER (Model AC-1)
Combo strobe & Chromatic
in Stomp Box Format _" a
True Bypass
Choose Note & Calibration
Large easy to read LEDs
Dual Outputs (mute & through) 33 I
Durable die oust housing I
Powers from 9V battery or
optional Morley 9V adapter
Two-year warranty
Hum XTM
ffM 7 Exterminate ground related
' hum right at the source!
g Maintains solid ground while
filtering ground line of low
voltages & currents that
cause hum. Simply place on
power plug of offending gear
and youre donel
' Hum Ehmmaibi
WWEBTEEE-Humgliminqtog TBS
vx/nggjggfgi *Hum Eliminator /
HUM ELIMINATORW'
Eliminates ground loop hum. Also converts between balanced
and unbalanced signals. Available in four versions:
HE-2: Two channel box with 1/4" Smart Jacks (TS or TRS)
HE-2-XLR: Two channel box with 1/4 Smart Jacks & XLR
HE-B: Eight channel single space rack with 1/4" Smart Jacls
HE-B-XLR; Eight channel single space rack with XLR Jacks
43 TECHgI-IneLeVeI SIM,
LpTEKCH Line Level i"
LINE LEVEL SHIFTER®
Increase or decrease signal voltage (-10dBV and +4dBu) without
adding noise. Also eliminates ground loop hum & converts
balanced and unbalanced signals. Available in four versions:
LLS-2: Two channel box with 1/4" Smart Jacks (TS or TRS)
LLS-2-XLR: Two channel box with 1/4l Smart Jacks 8. XLR
LLS-B: Eight channel single space rack with 1/ Smart Jacks
LLS-8-XLR: Eight channel single space rack with XLR Jacks
6-IN-1 CABLE TESTER
0 Cable IMring Display
0 Intermittent Detect& Display
0 Installed Cable Testing
0 Test Tone Generator
0 Phantom Power Detector
O Grounded Shield Detector
0 Checks XLR, 1/ RCA,
1/ '|'|'& 3 Pin MIDI cables
Sound Enhancement Products, Inc.
325 Cary Point Drive Cary IL 60013 USA
Toll Free (800) 284-5172
Phone (847) 639-4646
Fax (847) 639-4723
www.morleypedals.com
www.ebtechaudio.com
Reorder MAD-102000000 Rev Jul12
GEORGE LYNCH DRAGON 2 WAH
(Model GLW2)
O Switchless & EIectro-Optical
o O THREE foot-selectable Wah modes:
- Traditional llllah, WOWand Wah Lock
0 Control Wah Level in any Wah mode
0 Wah Lock lets you use pedal as tone
filter. NOTCH dials in Wah "position"
7 ,_, O TrueTone Bypass buffer circuk
0 LED indication, Quick Clip battery
door and two-yearwarranty.
0 Works with BASS tool
STEVE VAI BAD HORSIE WAH
(Model VAI-1)
O Switchless and Electra-Optical
Vllah set to Steve Vai's
precise specifications
0 TrueTone Bypass buffer circuit
0 LED indication, Quick Clip battery
door and two-year warranty.
0 Works with BASS too!
STEVE VAI BAD HORSIE 2
CONTOUR WAH (Model VAI-2)
O 2 foot-selectable Wan modes:
1a" Bad Horsie & Contour Wah
O In Contour mode, adjust the
Wah frequency and level
9 O Switchless 8. Electra-Optical
O TrueTone Bypass buffer circuit
0 LED indimtion, Quick Clip
battery door and two-year
warranty.
0 Works with BASS tool
MARK TREMONTI WAH
(Model MARK 1)
O Switchless & Electra-Optical
O 20dB ofWah Boost
0 TrueTone Bypass buffer circuit
0 LED indication, Quick Clip
battery door and two-year
warranty.
0 Works with BASS tool
_ ,y "7/ c
STEVE VAI LITTLE ALLIGATOR
VOLUME (Model PLA)
0 Electra-Optical circuitry
0 Smooth linear taper
0 Designed for use in effects loop
or in front amp input
sv 0 Minimum Volume for balancing
o WI/Wear between rhythm/lead volumes
3 0 LED indication, Quick Clip
battery door and two-year
warranty.
0 Works with BASS or KEYS too!
T.M. STEVENS FONKWAH
(Model m3)
0 Switchlees & Electra-Optical
0 Two foot-selectable Wah modes;
Tladitional Wah and Fonk Wah
O Fonk Wah is a very percussive tone
great for slappin' and poppin
0 Adjust Wah level in any mode
I Input Trim for adjusting between
Active and Passive pickups
O TrueTone Bypass buffer circuit
0 LED indication, Quick Clip battery
door and two-year warranty.
0 Works with GUITAR tool
PRO SERIES II DISTORTION
WAH VOLUME (Model PDW~II)
O Vllah, Volume and Distortion in one pedal '
O Wan and Volume are Electro-Optical . L
0 High Q Wah Tone (More low/high) r I ~
0 Classic analog distortion with .. '
Drive, Level & Tone control any i
0 Use any effect individually or attack? p
use dist w/ Vlbh or dist wlvolume
O TrueTone Bypass buffercircuit
0 LED indication, Quick Clip battery
door and two-year warranty.
0 Works with BASS tool
POWER WAH (Model PWO)
r O Electra-Optical circuitry
\ 0 Vintage Wah tone
2» O TrueTone Bypass buffer circuit
0 LED indication, Quick Clip
battery door and two-year
warranty.
0 Works with BASS tool
POWER WAH VOLUME (Model PWOV)
O Elelzro-Optical Wah & Volume
0 Vintage Wah tone
0 Smooth Audio taper '7 s
O TrueTone Bypass buffer circuit
0 LED indication, Quick Clip " n
battery door and two 9
year warranty.
0 Works with BASS too!
CLASSIC WAH (Model CLW)
O Wah tone of Morley pedals
of 70's 8. 80's
)5 « 0 LED indication, Quick Clip
Then?) 0 battery door and two
"WY , year warranty.
0 Works with BASS tool
DUAL BASS WAH (Model PEA-2)
0 Switchless & EIectro-Optical
0 Two Wah modes; Traditional
Wah and Funk Wah
0 Control Wah level in either mode
0 TrueTone Bypass buffer circuit
0 LED indication, Quick Clip battery 3
door and two-year warranty.
0 Works with GUITAR tool
VOLUME PLUS
(Model on+)
O Electro-Optical Circuitry
0 Smooth Audio taper
J a O Switchable Minimum Volume
.s-% i 0 Minimum Volume for Rhythm
magi/>3! 0 8. Lead Volume control
My 1 0 LED indication, Quick Clip
. battery door and tw04year
warranty.
0 For GUITAR, BASS or KEYSI
OPTICAL VOLUME (Model EOV)
Professional Grade \kalume
pedal at affordable price
EIectro-Optical circuitry ..
Studio-Quiet Audio taper 3:
LED indication, Quick Clip ?Q<> "' 0
battery door and two-year (g.
warranty. -
For GUITAR, BASS or KEYSI
GAS STATION (Model GS-1)
0 9 Volt Regulated Multi power supply
0 Power up to eight FX pedals, up to
250 mA per outlet
0 Center Polarity negative
0 Each outlet has fault LED to show
short or overload - remaining outlets
continue to workl
0 Includes main power adapter and
eight 2 ft connector cables
0 Compatible with most other FX brands
ABY (Model ABY)
., 0 Route one signal to lvvo outputs
I or two inputs to one output.
0 Choose A, B orA & B combined.
d 0 LED's show which signal is active
Am. 91 0 Passive & True Bypass
'5 0 Cold Rolled Steel housing and
Quick Clip battery door
0 Power from 9V battery or adapter
0 Two-year warranty
ABC (Model ABC)
0 Route 1 guitar to 3 amplifiers,
Select/combine amps as needed.
0 Route 3 guitars to 1 amplifier,
Select guitars with footswitches,
0 LED's show which signal is active .. .
0 Passive and True Bypass
0 Powers from 9V battery (for LEDs) 7.,
or optional Money 9V Adapter
0 Cold Rolled Steel Housing and
Quick Clip battery door
0 Two-year warranty
GEORGE LYNCH TRIPLER
(Model Tripler)
0 Route 1 guitar to 3 amps
O Select/combine as needed
0 LED Indication
0 Up to 20dB of clean boost
0 Powers from 9V battery
or Morley 9V Adapter
79 0 Cold Rolled Steel housing
and Quick Clip battery door
0 Two-yearwarranty
QUAD BOX (Model QUAD)
0 Route 2 guitars to 2 amps
0 Select between either guitar
0 Use any combination of
both amplifiers
0 LED's show you which guitars
and amps are on/off
0 Powers from 9V battery (for
LEDs) or Morley 9VAdapter
0 Passive and True Bypass
0 Cold Rolled Steel housing and
Quick Clip battery door
0 Two-year warranty
ADAPTER (Model Morley 9V)
0 9 Volt 300 mA Regulated power supply
7/ in US and European Versions
1/ 0 Center Polarity negative
0 Handy LED shows adapter is working
a. O Morley pedals require the use of Money
adapter. Using other brand adapters
may cause your Morley to hum.
0 Compatible with most other FX brands
//
