SPECIFICATIONS

from unit to unit.

NOTE
All specifications are typical and may vary slightly

POWER REQUIREMENTS

Operating Voltage Input to
Instrument

Power Consumption
CONTROLLERS
Keyboard

GLIDE control

TUNE Control

MODULATION RATE
Control

MODULATION SHAPE
Switch

OSC MODULATION Amount

VFC MODULATION
Amount

PITCH WH EEL Range
OSCILLATORS

Reference frequency for Low F

(Octave = 32')

OSC 1
OSC 2

WAVE FORMS
OSC I

OSC 2

OCTAVES
OSC l and OSC 2

SYNC OSC 2 TO
OSC 1, ON

SYNC OSC 2 TO OSC I.
CONTOURED

OSC 2 INTERVAL Control
CONTOUR GENERATOR

ATTACK Time
Minimum
Maximum

24 volts AC nominal, 28 volts
AC maximum; 50-60 Hertz

6 watts

32 note ( F to CI

Linear, continuously variable
from 5 msec to 23 sec

+/- 3 semitones

3H2 to 31Hz

Triangle, Square or Sample
and Hold

Zero to 18 semitones

Zero to 4 octaves

+/- 7 semitones

43.65Hz
43.65Hz

Sawtooth and 50% duty
cycle: Square wave
Sawtooth and 85% duty
cycle; Pulse wave

32, 16', 8

Locks the fundamental fre-
quency of OSC 2 to OSC 1;
INTERVAL control sweeps
OSC 2 four octaves

Locks the fundamental Ire-
quency of OSC 2 to OSC I:
Contour envelope sweeps
OSC 2 through the CON-
TOUR AMT Control (four
octaves)

16 semitones

4 milliseconds
6 seconds

DECAY Time
Minimum
Maximum
Sustain Level at U128 with

Key depressed and SUSTAIN
Switch IN

10 milliseconds
20 seconds

4.3 volts

VOLTAGE CONTROLLED FILTER (VCFI
Type: Patented 24dB/octave low pass filter

KEYBOARD TRACKING

Regeneration Frequency with
FILTER CUTOFF Control
centered, KEYBOARD
TRACKING min.,
CONTOUR AMT min.

Range of FILTER CUTOFF
Control

FILTER CONTOUR AMT
Range

Zero to 100% of keyboard
control voltage effects the
filter cutoff

740Hz

11 octaves

6.3 octaves

VOLTAGE CONTROLLED AMPLIFIER (VCAI
iAll outputs measured at AUDIO OUT)

OSC I Sawtooth
OSC 2 Sawtooth
NOISE

REAR PANEL 0
KEYBOARD IN
KEYBOARD OUT
STRIGGER IN

S~TRIGGER OUT

V-TRIGGER IN

V-TRIGGER OUT

AUDIO IN

SIGNAL TO NOISE RATIO

Bleedthrough (all levels down,

MASTER VOL max)

WEIGHTS AND DIMENSIONS

Synthesizer Dimensions

Synthesizer Weight

Carton Dimensions

Shipping Weight

- ZdB
- ZdB
+6dB

1 volt per octave
1 volt per octave

Short to ground triggers
CONTOUR GENERATOR

Shorts J2 pin 5 to ground
when key is depressed

+3 to 10 volt gate triggers
CONTOUR GENERATOR
+10 volts when key is
depressed

Signal is processed by VCF
and VCA: 18K input
impedance

SOdB

21" wide x 12-1/2" deep x
54/4" high

(53cm x 325m x 123ch

II pounds ISkg)

234/8" long x Id" wide x
Gel/4" high

(59cm x 36cm x 59cm)

14 pounds (6.3kg)
